Keithley 3706A | Modular switching and data acquisition system, basic device, 6-slot mainframe, integrated 7.5-digit high-performance digital multimeter, up to 576 multiplexer channels.

Name: 3706A | Modular switching and data acquisition system, basic device, 6-slot mainframe, integrated 7.5-digit high-performance digital multimeter, up to 576 multiplexer channels.
Brand: Keithley
SKU: 3706A
Price: 5270.0 EUR
Availability: OutOfStock

Manufacturer number: 3706A

Reordered - in stock. Delivery time on request

€5,270.00

plus VAT. €6,271.30 VAT plus shipping costs

or choose one of the following options:

Product inquiries Request education-price

Keithley 3706A | Modular switching and data acquisition system, basic device, 6-slot mainframe, integrated 7.5-digit high-performance digital multimeter, up to 576 multiplexer channels.

Mainframe with 6 slots, diverse selection of plug-in modules for optimal and future-oriented application flexibility
With display for the measured value display
Integrated 7½-digit digital multimeter: 26-bit resolution, basic accuracy 0.0009% (1 to 10 V), DC sampling rate> 14,000 readings / s (for 3.5 digits), extended low-resistance (1 Ω) and low-current Measuring range (10 μA)
Measuring speed up to 14,000 readings / s
Voltage measurement: 10 nV to 300 V (DC), 100 nV to 300 V (AC)
Current measurement: 1 pA to 3 A (DC), 1 nA to 3 A (AC)
Frequency measurement: 3 Hz to 500 kHz
Temperature measurement: -200 to +1820 ° C (RTD RTD, TC thermocouples, thermistors)
Extended measurement options in the low current (10 µA) and low ohm range (1 Ω)
13 measurement functions including DCV, ACV, DCI, ACI, frequency, period, two-wire ohm, four-wire ohm, three-wire RTD temperature, four-wire RTD temperature, thermocouple temperature, thermistor Temperature, continuity
Internal memory for max. 650,000 measured values, extended data storage via USB stick
Interfaces: USB (front and back), LAN, GPIB, LXI
Power supply: 100/240 V AC, 50/60 Hz
Dimensions: W 483 x H 104 x D 457 mm (tabletop unit)
Weight: 13 kg (transport weight)

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

2-/4-wire:	2-/4
Accuracy voltage measurement AC:	0,05 %
Accuracy voltage measurement DC:	0,003 %
Article number:	3706A
Available modules:	3720: Dual 1×30 Multiplexer Card (Auto CJC when used with 3720-ST) 3721: Dual 1×20 Multiplexer Card (Auto CJC when used with 3721-ST) 3722: Dual 1×48, High Density, Multiplexer Card 3723: Dual 1×30, High Speed, Reed Relay Multiplexer Card 3724: Dual 1×30
Connection types:	D-Sub
Current measuring range AC:	1 mA - 3 A
Current measuring range DC:	10 µA - 3 A
Dimensions (L x W x H) (mm):	457 x 483 x 104
Diode test / continuity test:	No / Yes
Display:	numerical
Frequency measuring range:	3 Hz - 500 kHz
Interfaces:	LAN, USB, GPIB
Measured value memory:	Buffer: 650.000
Measurements per second:	14000
Model:	3706A
Number of DMM positions:	7.5
Number of channels:	576
Number of plug-in modules:	6
Number of positions:	7.5
Resistance measuring range:	1 Ω - 100 MΩ
Special features:	Embedded Web Interface
Temperature measurement:	Yes
Temperature measuring range:	-200 °C - 1820 °C
Voltage measuring range AC:	100 mV - 300 V
Voltage measuring range DC:	10nV - 300V
Warranty (years):	3
Weight (kg):	13
max. Measuring range DC (V):	300
min. Measuring range DC (mV):	100

Description

3706A | Modular switching and data acquisition system, basic device, 6-slot mainframe, integrated 7.5-digit high-performance digital multimeter, up to 576 multiplexer channels.

The 3700A series switching and data acquisition system offers scalable, device-specific switching and multichannel measurement solutions that are optimized for the automated testing of electronic products and components. The 3700A series comprises four variants of the data logger mainframe 3706A, whereby two basic devices are equipped with an integrated 7½-digit high-performance digital multimeter (DMM). All basic units 3706A each contain six slots for plug-in modules in a compact housing that is only 2 U high.

When fully populated, a 3706A mainframe can support up to 576 dual-line multiplexer channels, providing unprecedented channel density and cost savings per channel. The result is a fully integrated switching and measurement solution that is equally suitable for use in the laboratory or in a rack.

Variety of applications thanks to plug-in cards:

The wide functionality of the available plug-in cards makes the 3700A data acquisition system a flexible and economical measurement solution. Up to six modules can be used in the basic unit 3706A and thus configure it to a compact data logger, a full measurement data acquisition system or a cost-effective switching unit. When fully occupied, a mainframe can support up to 576 multiplexer channels with two lines. The growing family of plug-in switching and control cards, together with the internal high-performance DMM, enables the construction of a compact measuring and switching system for functional tests in the laboratory and in production environments.

3720: Dual 1 × 30 multiplexer (Auto “Cold Junction Compensation” = automatic temperature compensation of the connection point when using the screw connection 3720-ST)
3721: Dual 1 × 20 multiplexer (Auto “Cold Junction Compensation” = automatic temperature compensation of the connection point when using the screw connection 3720-ST)
3722: Dual 1 × 48 high density multiplexer
3723: Dual 1 × 30 Reed Relay Multiplexer, High Speed
3724: Dual 1 × 30 FET multiplexer
3730: 6 × 16 high density matrix
3731: 6 × 16 Reed Relay Matrix, High Speed
3732: Quad 4 × 28, Reed Relay Matrix, Ultra-High Density
3740: 32-channel switch module
3750: multifunction module
3760: 10-channel high current multiplexer
3761: 10-channel low current multiplexer
3762: 10-channel high voltage multiplexer
3765: Hall effect card

Software for controlling the matrix system:

Measurement paths and measurements can be set or carried out with the 3700A in two ways: either via the PC or via a test script processor (TSP). The TSP increases the test speed considerably. Development times and costs for test programs and in particular the test duration in production can be reduced as a result. By creating a test script that is loaded into the integrated microprocessor, self-sufficient test procedures can be carried out. The bypassed slow PC device communication leads to a significantly higher test throughput.

All 3706A mainframes contain a USB interface on the front for easy transfer of measured values, system configurations and TSP test scripts to memory sticks.

Lieferumfang

Test Script Builder for the rapid development of test scripts for automated measurement processes
Test Script Builder Software Suite (CD)
CA-180-3A Ethernet cable
CD with driver for LabVIEW, IVI C, IVI.COM

Accessoires (21 products )

Keithley 3720
