TDK-Lambda G600-12.5-3P | Genesys+ power supply, DC, 1 channel, 1U, 150V / 50A, 7.5kW, LAN, Iso. Analogue, USB, RS-232

Name: G600-12.5-3P | Genesys+ power supply, DC, 1 channel, 1U, 150V / 50A, 7.5kW, LAN, Iso. Analogue, USB, RS-232
Brand: TDK-Lambda
SKU: G600-12.5-3P480
Availability: OutOfStock

Manufacturer number: G600-12.5-3P480

Delivery time upon request

On Request

or choose one of the following options:

Product inquiries

TDK Lambda G600-12.5-3P | Genesys+ power supply, DC, 1 channel, 1 U, 150 V / 50 A, 7.5 kW, LAN, Iso. Analogue, USB, RS-232.

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

AC input:	342 V - 528 V
Additional functions:	Arbitrary generator with memory function programmable edge control constant voltage, constant current, constant power internal resistance simulation
Article number:	G600-12.5-3P480
Autorange:	No
Bidirectional:	No
DC output reversible:	DC Source
Dimensions (L x W x H) (mm):	486,5 x 423 x 43,6
Interfaces:	LAN, USB, RS-232/RS-485 isolated analog interface
Model:	G600-12.5-3P480
Output power (kW):	7.5
Power factor:	0,94 @ 200 VAC / 380 VAC
Protective devices:	OVP, UVP, UVL, FOLD (CV/CC), OCL, OTP, AC FAIL
Warranty (years):	5
Weight (kg):	8.5
max. Power (A):	12.5
max. Voltage (V):	600

Description

G600-12.5-3P | Genesys+ power supply, DC, 1 channel, 1U, 150V / 50A, 7.5kW, LAN, Iso. Analogue, USB, RS-232
