SPS S1801M | Multifunctional safety tester according to VDE / EN standards

Manufacturer number: S1801M

S1801M
S1801M
S1801M
S1801M
Delivery time upon request

€3,272.00

plus VAT. €3,893.68 VAT plus shipping costs

or choose one of the following options:
Request a quote Product downloads Product inquiries
Highlights Documents / Downloads Description Related Articles

PLC S1801M | Multifunctional safety tester VDE for high voltage tests, insulation measurements and protective conductor tests.

  • Display: 4.3 “TFT color display
  • Interfaces: 2 x USB, RS 232, Ethernet / LAN
  • Socket for PE81-i protective conductor test
  • Voltage range high voltage test AC: 100 ... 5,500 V
  • Current range high voltage test AC: 0 ... 3 mA
  • Voltage range high voltage test DC: 100 ... 6,000 V
  • Current range high voltage test DC: 0 ... 10 mA
  • Voltage range insulation measurement DC: 100 ... 6,000 V
  • Measuring range insulation measurement DC: (depending on voltage) 250 kΩ ... 10 GΩ
  • Measuring range protective conductor test: 0 ... 400 mΩ
  • Test current AC protective conductor test: 10 ... 30 A
  • Open circuit voltage protective conductor test: 6 V or 12 V
  • Dimensions: (HxWxD) 159 mm x 360 mm x 331 mm
  • Weight: approx. 11.0 kg

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Datasheet
pdf | 0.13 MB

Description

S1801M | Multifunctional safety tester according to VDE / EN standards

The SPS multifunction tester S 1801M can be seen as a combination of the successful high voltage tester HA 1800M and the popular protective conductor tester P 1800D. The PLC multifunction tester S 1801M is the successor of the popular S1800M - the S 1801M has an additional socket on the back of the device, which enables the connection of a PE81-i protective conductor test pin.

Thanks to the integrated safety current limitation, you can carry out standard-compliant tests without the need for additional protection in accordance with EN 50191.
Perform high-voltage tests, insulation measurements and protective conductor tests with one device. The multifunction tester is the intuitive and cost-effective way to carry out safety tests in accordance with most of the common international standards (IEC, EN, UL, VDE ...).

User information:

Use of the connection console A8 / 3800-P only in connection with protective conductor test pin PE81-I. When using without a desk, we recommend the PE81-x / 2 protective conductor test pin in conjunction with ST14-14.

Accessoires (2 products)

Accessoires (2 products)

A7 / 3800-P
Exclusive
SPS
A7 / 3800-P
DUT connection, 4 x power sockets & laboratory sockets for safety tester S 1800M
Delivery time upon request
€581.00
R2 / S1801M
Exclusive
SPS
R2 / S1801M
Warranty extension S1801M to 2 years
Delivery time upon request
€130.88
