Rohde&Schwarz FSVA3004 | Signal and spectrum analyzer, FSVA3000 series, 10 Hz to 4 GHz, RBW 1 Hz to 10 MHz, -120 dBc/Hz (1330.5000.05)

Name: FSVA3004 | Signal and spectrum analyzer, FSVA3000 series, 10 Hz to 4 GHz, RBW 1 Hz to 10 MHz, -120 dBc/Hz (1330.5000.05)
Brand: Rohde&Schwarz
SKU: 1330.5000.05
Availability: InStock

Manufacturer number: 1330.5000.05

Delivery time upon request

On Request

or choose one of the following options:

Request a quote Product inquiries Request education-price

Rohde & Schwarz FSVA3004 | Signal and spectrum analyzer, frequency range 10 Hz to 4 GHz, analysis bandwidth up to 400 MHz, optional 10 Gbit / s LAN (1330.5000.05).

Frequency range: 10 Hz to 4 GHz
Resolution bandwidth (-3 dB): 1 Hz to 10 MHz
Analysis bandwidth: 28 MHz (standard), optional: 40, 200, 400 MHz
SSB phase noise: -120 dBc (1 Hz) at 10 kHz offset (1 GHz carrier spacing)
TOI (Third-Order Intercept): 20 dBm (typ.) At 1 GHz
DANL: -153 dBm (typ.) At 1 GHz, -167 dBm (typ.) At 1 GHz with PreAmp on (optional)
Measurement application for analog and digital signal analysis incl. 5G NR
Maximum input power: 30 dBm
Marker resolution: 1 Hz
Interfaces: 5x USB 2.0 type A, 2x USB 3.0 type A, 2x reference input / output, external trigger, LAN 10/100 / 1000BASE-T, DVI for external monitor, optional: GPIB, 10 Gbit / s LAN, USB 3.0 type B, Display port for external monitor
Power supply: 100 to 240 V AC, 50/60 and 400 Hz
Dimensions: W 462 × H 197 x D 417 mm
Weight: 12.2 kg
Warranty: 3 years

Technical Data

Amplitude range:	-162 dBm to 30 dBm
Analysis bandwidth (MHz):	400
Article number:	1330.5000.05
DANL Displayed Average Noise:	-162 dBm
Demodulations:	Optional: AM, FM
Detectors:	max. peak, min. peak, auto peak (normal), sample, RMS, average, with K54 quasi-peak, RMS-average, CISPR-average
Dimensions (L x W x H) (mm):	417 x 462 x 197
Dynamics:	192 dB
Filter bandwidths:	1 Hz to 10 MHz in 1/2/3/5 sequence, additional 6 and 8 MHz, CISPR 200 Hz, 9 kHz, 120 kHz, 1 MHz optional
Frequency stability:	1ppm
Interfaces:	USB, LAN, Trigger in, Ref out, Ref in, DVI Optional: GPIB, HDMI
Measurement functions:	FSV3-K10 GSM/EDGE/EDGE Evolution/VAMOS measurements, FSV3-K72 3GPP FDD (WCDMA) BS measurements, FSV3-K73 3GPP FDD (WCDMA) MS measurements (incl. HSUPA and HSUPA+), FSV3-K100 EUTRA/LTE FDD BS measurements, FSV3-K101 EUTRA/LTE FDD UE measurements, FSV3-K102
Model:	FSVA3004
Resolution bandwidth:	0,01 Hz
SSB phase noise:	-120 dBc/Hz @ 1 GHz (10 kHz carrier offset) Optional: B710 -127 dBc/Hz
Screen size:	25,6 cm
Screen type:	1280 x 800, TFT LCD
Special features:	extensive measurement applications, 400 MHz analysis bandwidth optional (28 MHz standard), external generator as tracking generator optional
Sweep:	linear, logarithmic
Tracking-Generator:	external optional
Warranty (years):	1
Weight (kg):	12.2
max. Frequency range (GHz):	4
min. Frequency range (kHz):	0.002

Description

FSVA3004 | Signal and spectrum analyzer, FSVA3000 series, 10 Hz to 4 GHz, RBW 1 Hz to 10 MHz, -120 dBc/Hz (1330.5000.05)

Up to 400 MHz analysis bandwidth, low phase noise of only -120 dBc / Hz and a high dynamic range: The signal and spectrum analyzer FSVA3004 comes for the most demanding measurement applications in the mobile radio industry, in the component industry, in aviation and for service - and maintenance tasks in the A&D market. The RF parameters can be adjusted intuitively via a multi-touch display with a graphical user interface; the auto set function supports you in the automatic setting of the most important settings for frequency, level, etc. The SCPI recorder simplifies the test program development, and event-based actions help to debug rare signal appearances of a DUT.

For 5G and other radio standards:

The spectrum analyzer FSVA3004 is ideally suited for the analysis of wireless radio standards such as 3GPP 5G NR, NB-IoT, GSM / EDGE, WLAN 802.11, LTE, WCDMA and much more. in research and development, in production, during system tests or during design verification. Thanks to the very large analysis bandwidth of 400 MHz, four neighboring 5G-NR carriers can be recorded in parallel. Special options for 5G signal analysis achieve EMC values of less than 1% for a 100 MHz wide carrier (at 28 GHz).

High measuring speed for production:

The FSVA3004 signal and spectrum analyzer was designed for high-speed applications in automated test systems and is used for fast spectral measurement and signal demodulation in the manufacture of electronic components, modules and devices. An optional quad-core CPU accelerates signal demodulation; An internal PCIe 3.0 bus system enables the ultra-fast transmission of the measurement data. In cloud-based test systems, the optional LAN interface with 10 Gbit / s enables the fast transfer of I / Q data to the network side.

Lieferumfang

Signal and spectrum analyzer FSVA3004
1x adapter FSVA3030, 3.5 mm (female / female)
1x adapter FSVA3044, 2.92 mm, (female / female)
Quick start guide
Power cord
