Rohde&Schwarz SMB100B | Signal generator basic unit, 8 kHz - 1 / 3 or 6 GHz frequency range (1422.1000.02)

Manufacturer number: 1422.1000.02

Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Rohde&Schwarz SMB100B
Delivery time upon request

On Request

or choose one of the following options:
Product downloads Product inquiries Request education-price
Highlights Documents / Downloads Description Scope Related Articles

Rohde & Schwarz SMB100B | HF signal generator, 8 kHz… 1/3/6 GHz, max. Output power +34 dBm, SSB phase noise <–132 dBc (typ.) (1422.1000.02).

  • Frequency range: 8 kHz… 1/3/6 GHz (depending on the option)
  • Single sideband phase noise (SSB): <–132 dBc (measured) at 1 GHz and an offset of 20 kHz
  • Broadband noise: <–153 dBc (typ.) At 15 MHz <f ≤ 6 GHz and an offset of 30 MHz
  • Output power: 34 dBm (measured) at 1 GHz
  • Dimensions: 2 U, 3/4 19 “width
  • Warranty: 3 years

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Brochure
pdf | 2.98 MB
Datasheet
pdf | 2.93 MB
Userguide
pdf | 11.93 MB
Start guide
pdf | 0.98 MB

Description

SMB100B | Signal generator basic unit, 8 kHz - 1 / 3 or 6 GHz frequency range (1422.1000.02)

The new R&S SMB100B RF signal generator stands for performance and versatility in a small footprint. The impressive features of the SMB100B include outstanding spectral purity and very high output power combined with extensive functionality and very easy operation.

Thanks to the innovative synthesizer, the SSB phase noise is just <–132 dBc (measured) at 1 GHz and an offset of 20 kHz. The output power can be increased with options K31 and B32 up to 34 dBm (measured) at 1 GHz. Depending on the option selected, the Rohde & Schwarz SMB100B offers a frequency range from 8 kHz to 1 GHz, 3 GHz or 6 Ghz.

The large 5 “touch display enables intuitive operation. Define your own user menu and access the functions you need even faster.

Lieferumfang

  • SMB100B
  • Power cord
  • Quick start guide

Accessoires (17 products )

Rohde&Schwarz SMBB-B32
Rohde&Schwarz SMBB-B32
Ultra High Output Power for SMBB-B101, SMBB-B103, SMBB-B106, hardware option (1422.5740.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K720
Rohde&Schwarz SMBB-K720
AM/FM/PhiM, for SMB100B, retrofit (1422.6201.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K704
Rohde&Schwarz SMBB-K704
Flexible reference input from 1 MHz - 100 MHz, for SMB100B, retrofit (1422.6301.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K24
Rohde&Schwarz SMBB-K24
Multifunction generator, for SMB100B, retrofit (1422.6053.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B5
Rohde&Schwarz SMBB-B5
Stereo/RDS encoder, for SMB100B, hardware option (1422.5605.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B3
Rohde&Schwarz SMBB-B3
1 GHz reference input/output, for SMB100B, hardware option (1422.5505.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B86
Rohde&Schwarz SMBB-B86
Remote control interface GPIB and USB, for SMB100B, hardware option (1422.5805.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K31
Rohde&Schwarz SMBB-K31
High Output Power, for SMBB-B101, SMBB-B103, SMBB-B106, retrofit (1422.5705.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B103
Rohde&Schwarz SMBB-B103
Frequency range: 8 kHz - 3 GHz Hardware option, cannot be retrofitted (1422.5105.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B1
Rohde&Schwarz SMBB-B1
Reference oscillator, OCXO, for SMB100B hardware option (1422.5305.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K22
Rohde&Schwarz SMBB-K22
Pulse modulator, for SMBB-B101/B103/B106, retrofit (1422.5905.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B1H
Rohde&Schwarz SMBB-B1H
Reference oscillator, OCXO, high stability for SMB100B, hardware option (1422.5405.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B106
Rohde&Schwarz SMBB-B106
Frequency range: 8 kHz - 6 GHz Hardware option, cannot be retrofitted (1422.5205.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K27
Rohde&Schwarz SMBB-K27
Pulse Train, for SMB100B, retrofit (1422.6101.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B101
Rohde&Schwarz SMBB-B101
Frequency range: 8 kHz - 1 GHz Hardware option, cannot be retrofitted (1422.5005.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K23
Rohde&Schwarz SMBB-K23
Pulse generator, for SMB100B, retrofit (1422.6001.03)
Delivery time upon request
On Request
Rohde&Schwarz ZZA-S234
Rohde&Schwarz ZZA-S234
Adapter, rack, 19 inch, 2 HE 3/4, including shock protection (1109.4493.00)
Delivery time upon request
€345.00

Options (16 products )

Rohde&Schwarz SMBB-B101
Rohde&Schwarz SMBB-B101
Frequency range: 8 kHz - 1 GHz Hardware option, cannot be retrofitted (1422.5005.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B103
Rohde&Schwarz SMBB-B103
Frequency range: 8 kHz - 3 GHz Hardware option, cannot be retrofitted (1422.5105.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B106
Rohde&Schwarz SMBB-B106
Frequency range: 8 kHz - 6 GHz Hardware option, cannot be retrofitted (1422.5205.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B1
Rohde&Schwarz SMBB-B1
Reference oscillator, OCXO, for SMB100B hardware option (1422.5305.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B1H
Rohde&Schwarz SMBB-B1H
Reference oscillator, OCXO, high stability for SMB100B, hardware option (1422.5405.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B3
Rohde&Schwarz SMBB-B3
1 GHz reference input/output, for SMB100B, hardware option (1422.5505.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B5
Rohde&Schwarz SMBB-B5
Stereo/RDS encoder, for SMB100B, hardware option (1422.5605.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K31
Rohde&Schwarz SMBB-K31
High Output Power, for SMBB-B101, SMBB-B103, SMBB-B106, retrofit (1422.5705.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B32
Rohde&Schwarz SMBB-B32
Ultra High Output Power for SMBB-B101, SMBB-B103, SMBB-B106, hardware option (1422.5740.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-B86
Rohde&Schwarz SMBB-B86
Remote control interface GPIB and USB, for SMB100B, hardware option (1422.5805.02)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K22
Rohde&Schwarz SMBB-K22
Pulse modulator, for SMBB-B101/B103/B106, retrofit (1422.5905.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K23
Rohde&Schwarz SMBB-K23
Pulse generator, for SMB100B, retrofit (1422.6001.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K24
Rohde&Schwarz SMBB-K24
Multifunction generator, for SMB100B, retrofit (1422.6053.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K27
Rohde&Schwarz SMBB-K27
Pulse Train, for SMB100B, retrofit (1422.6101.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K720
Rohde&Schwarz SMBB-K720
AM/FM/PhiM, for SMB100B, retrofit (1422.6201.03)
Delivery time upon request
On Request
Rohde&Schwarz SMBB-K704
Rohde&Schwarz SMBB-K704
Flexible reference input from 1 MHz - 100 MHz, for SMB100B, retrofit (1422.6301.03)
Delivery time upon request
On Request
