Rohde&Schwarz ZND | Vector Network Analyzer, 100 kHz to 4.5 GHz, 2-Port, 1 Hz to 300 kHz (1328.5170.92)

Manufacturer number: 1328.5170.92

Rohde&Schwarz ZND
Rohde&Schwarz ZND
Rohde&Schwarz ZND
Rohde&Schwarz ZND
Rohde&Schwarz ZND
Rohde&Schwarz ZND
Delivery time upon request

On Request

or choose one of the following options:
Product downloads Product inquiries Request education-price
Highlights Documents / Downloads Description Related Articles

Rohde & Schwarz ZND | Vector network analyzer, 2 gates, frequency range 100 kHz to 4.5 GHz, analysis bandwidth 1 Hz to 300 kHz, dynamic range up to 130 dB (1328.5170.92).

  • Frequency range: 100 kHz to 4.5 GHz, expandable to 8.5 GHz
  • Number of test ports: 2 goals
  • Maximum input power (test port): +27 dBm
  • Analysis bandwidth: 1 Hz to 300 kHz
  • DANL self-noise display: <typ. –125 dBm (1 Hz) at 50 MHz to 6.5 GHz
  • Dynamic range: typically 130 dB at 100 kHz to 6.5 GHz
  • Frequency resolution: 1 Hz
  • Over 100 measurement curves and channels
  • Test set expandable for bidirectional measurements
  • Comfortable calibration procedure
  • Wide level sweep range: 48 dB
  • Large, brilliant LCD screen: touchscreen, 12.1-inch diagonal for an optimal overview
  • Interfaces: 4x USB 2.0 type A, 2x USB 3.0 type B, LAN, reference input / output (10 MHz), DVI for external monitor, external trigger, optional: GPIB, handler I / O
  • Power supply: 100 to 240 V AC, 50/60 and 400 Hz
  • Dimensions: W 462.5 × H 239.6 x D 361.5 mm
  • Weight: 14 kg
  • Warranty: 3 years

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Brochure
pdf | 1.06 MB
Datasheet
pdf | 1.75 MB
Userguide
pdf | 16.35 MB
Start guide
pdf | 4.87 MB

Description

ZND | Vector Network Analyzer, 100 kHz to 4.5 GHz, 2-Port, 1 Hz to 300 kHz (1328.5170.92)

The vector network analyzer ZND from Rohde and Schwarz is used as a unidirectional basic network analyzer up to 4.5 GHz. It can be used to measure various parameters of an electronic network, e.g. B. the scattering parameters S 11 and S 21 according to amount and phase. In order to minimize the investment, measuring devices with reduced functionality are often sought in the production environment. The ZND offers an optimal solution for this. Its equipment enables, for example, the measurement of passive components such as filters, connectors or antennas. Options are available to extend the frequency range up to 8.5 GHz and to perform bidirectional measurements.

Due to its simple operation, the vector network analyzer ZND is also ideal for training purposes. The large color display with touch function enables the clear display of several measurement results.

The ZND network analyzer uses the same command set for remote control operation as the ZNB series devices. The measuring devices can thus be replaced if necessary without changing the control programs.

The ZND grows with your measuring tasks:

  • Easily expandable: time range analysis for cable and filter measurements, interfaces for controlling the measurement process in production environments, extended level sweep range
  • User- friendly calibration: the right calibration for every measurement application, automatic calibration in 30 s
  • Clear, flat menu structure for simple measuring processes: enables quick work and avoids operating errors
