Show all categories PXI Modules Back

PXI Modules

NI (National Instruments) PXI modules interface to bus standards and can be used to acquire data and images, trigger and synchronize measurement devices, generate and route signals, control motion, and perform a variety of measurements.

Filter
388 products
781421-15
NI
781421-15
NI 2815B, 4x86 reed matrix up to 0.3 A for NI SwitchBlock
  • Relaistyp: Reed
  • With case: Yes
€7,930.00
Delivery time upon request
778967-01
NI
778967-01
NI PXI-6511 digital input module (industrial grade), 64 inputs, bank isolated digital acquisition and NI-DAQ
  • With case: Yes
  • Number of digital inputs: 64
  • Logic level and range: 24 V, -30.0V - 30.0V
  • Logic level of the digital I/O: 24 V
€1,040.00
Delivery time upon request
780561-01
NI
780561-01
NI PXI-7952R, FlexRIO FPGA module (Virtex-5 LX50, 128 MB RAM)
  • With case: Yes
€10,600.00
Delivery time upon request
785769-01
NI
785769-01
PXIe-5111 PXI Oscilloscope, 350 MHz, 8 bits, 3 GS/s, 2 channels, 64 MB
  • With case: Yes
  • Bandwidth (MHz): 350
  • Voltage measuring range of the analogue input (V): -20 V bis 20 V
  • Number of analogue input channels: 2
  • Number of channels: 2
  • Measurements per second/sampling rate (MS/s): 3000
€8,030.00
Delivery time upon request
785173-01
NI
785173-01
PXIe-7912, FlexRIO FPGA coprocessor, KU040 FPGA, 4 GB DRAM, high speed serial I / O
  • With case: Yes
€18,900.00
Delivery time upon request
785586-01
NI
785586-01
PXIe-5785, FlexRIO-IF transceiver, 2 x 2 channels, 6.4 GS / s, KU060
  • With case: Yes
  • Number of analogue input channels: 2
  • Number of analogue output channels: 2
  • Measurements per second/sampling rate (MS/s): 6400
€36,800.00
Delivery time upon request
782878-01
NI
782878-01
NI PXIe-4322, Isolated Analog Output Module
  • With case: Yes
  • Max. Output current (mA): 20
  • Max. Update rate (MS/s): 0.25
  • Number of analogue output channels: 8
€4,740.00
Delivery time upon request
785926-01
NI
785926-01
PXIe-6386, multifunction I / O module with simultaneous AI acquisition (14 MS / s / ch, 16 bit)
  • With case: Yes
  • Number of analogue output channels: 2
  • Number of bidirectional digital channels: 24
  • Voltage measuring range of the analogue input (V): -5 V bis 5 V, -2 V bis 2 V, -10 V bis 10 V, -1 V bis 1 V
  • Number of counters/timers: 4
  • Max. Number of differential analogue input channels: 8
  • Measurements per second/sampling rate (MS/s): 14
  • Max. Update rate (MS/s): 3.3
€12,900.00
Delivery time upon request
784777-02
NI
784777-02
PXIe-5654, 20 GHz signal generator with amplifier extender; Quick switch
  • With case: Yes
  • RF generator frequency range (GHz): 250 kHz bis 20 GHz
  • max. Output power: 27
€54,300.00
Delivery time upon request
784144-01
NI
784144-01
PXIe-7847R, R-Series Multifunction I / O Module, Kintex-7 160T (512MB DRAM, 8 AI at 500 kS / s per channel, 8 AO at 1 MS / s per channel)
  • With case: Yes
  • Number of analogue output channels: 8
  • Voltage measuring range of the analogue input (V): -5 V bis 5 V, -2 V bis 2 V, -10 V bis 10 V, -1 V bis 1 V
  • Max. Update rate (MS/s): 1
  • Number of analogue input channels: 8
  • Number of bidirectional digital channels: 48
  • Logic level and range: 3.3 V, 1.5 V, 1.2 V, 2.5 V, 1.8 V
  • Logic level of the digital I/O: 3.3 V, 1.5 V, 1.2 V, 2.5 V, 1.8 V
  • Measurements per second/sampling rate (MS/s): 0.5
€7,210.00
Delivery time upon request
778572-67
NI
778572-67
NI PXI-2567, 64 Channel Relay Control Module
  • With case: Yes
€2,120.00
Delivery time upon request
781420-34
NI
781420-34
NI 2834A, 8X34 2-wire EMR matrix up to 2 A for NI SwitchBlock
  • With case: Yes
  • Relaistyp: Electromechanical
€4,730.00
Delivery time upon request
777531-01
NI
777531-01
NI PCI-6602, Counter/Timer with NI-DAQ for Windows XP/2000/NT/Me/9x, Mac
  • With case: Yes
  • Number of bidirectional digital channels: 32
  • Logic level of the digital I/O: 5 V TTL
  • Number of counters/timers: 8
  • Logic level and range: 5 V TTL
€1,520.00
Delivery time upon request
782622-01
NI
782622-01
PXIe-5162 PXI Oscilloscope, 1.5 GHz, 10 bits, 5 GS/s, 2 Channel, 64 MB
  • With case: Yes
  • Number of channels: 2
  • Bandwidth (MHz): 1500
  • Measurements per second/sampling rate (MS/s): 5000
  • Voltage measuring range of the analogue input (V): -25 V bis 25 V
€27,800.00
Delivery time upon request
52403P-25-10
Chroma
52403P-25-10
PXIe Short Pulse SMU, ± 25 V, DC, 3.5 A, 18 bit
€11,020.00
Delivery time upon request
783801-01
NI
783801-01
PXIe-6739, 16 bit, 64 analog outputs
  • With case: Yes
  • Number of counters/timers: 4
  • Max. Update rate (MS/s): 1
  • Max. Output current (mA): 10
  • Number of analogue output channels: 64
€5,460.00
Delivery time upon request
778572-75
NI
778572-75
NI PXI-2575, 196-channel multiplexer
  • With case: Yes
  • Relaistyp: Electromechanical
€3,800.00
Delivery time upon request
785770-11
NI
785770-11
PXIe-5111 PXI Oscilloscope with CableSense Technology, 350 MHz, 8 bits, 3 GS/s, 2 channels
  • With case: Yes
  • Bandwidth (MHz): 350
  • Voltage measuring range of the analogue input (V): -20 V bis 20 V
  • Number of analogue input channels: 2
  • Number of channels: 2
  • Measurements per second/sampling rate (MS/s): 3000
€12,500.00
Delivery time upon request
782359-01
NI
782359-01
NI PXI-2799, SPDT dual relay module up to 40 GHz
  • With case: Yes
  • Relaistyp: Electromechanical
€4,220.00
Delivery time upon request
783156-01
NI
783156-01
NI PXIe-5668R, VSA, 14 GHz, 2 GB RAM, 80 MHz bandwidth
  • With case: Yes
  • Number of input channels: 1
  • max. Frequency range (MHz): 14000
  • RF Analyzer Instant Bandwidth (GHz): 0.08
  • Average noise level: -166 dBm/Hz zwischen 300 MHz und 1.7 GHz
  • min. Frequency range (Hz): 20
€125,100.00
Delivery time upon request
781475-01
NI
781475-01
PXIe-6376, multifunction I / O module with 3.5 MS / s per channel (8 simultaneous AI, 24 DIO, 2 AO)
  • With case: Yes
  • Number of analogue output channels: 2
  • Number of bidirectional digital channels: 24
  • Voltage measuring range of the analogue input (V): -5 V bis 5 V, -2 V bis 2 V, -10 V bis 10 V, -1 V bis 1 V
  • Number of counters/timers: 4
  • Max. Number of differential analogue input channels: 8
  • Max. Update rate (MS/s): 3.3
  • Number of digital inputs: 0
  • Measurements per second/sampling rate (MS/s): 3.57
  • Number of digital outputs: 0
€10,700.00
Delivery time upon request
780340-01
NI
780340-01
R series multifunction device PXI-7852R, Virtex-5 LX50, 8 AI, 8 AO, 96 DIO, 750 kS / s
  • With case: Yes
  • Number of analogue output channels: 8
  • Max. Update rate (MS/s): 1
  • Number of analogue input channels: 8
  • Logic level of the digital I/O: 3.3 V, 5 V
  • Voltage measuring range of the analogue input (V): -10 V bis 10 V
  • Number of bidirectional digital channels: 96
  • Measurements per second/sampling rate (MS/s): 0.75
  • Logic level and range: 3.3 V, 5 V
€12,800.00
Delivery time upon request
780687-02
NI
780687-02
NI PXI-8512, CAN interface card, high speed / flexible data rate, 2 connections
  • With case: Yes
  • CAN physical layer: High-Speed, Flexible Data-Rate
  • Communication protocol: CAN
  • Number of CAN connections: 2
€3,000.00
4 in stock. Ready to ship in 1 business day
780587-29
NI
780587-29
PXIe-2529, PXI matrix switch with 128 crosspoints, electromechanical relay (1 A, 150 V)
  • With case: Yes
  • Relaistyp: Electromechanical
€4,240.00
Reordered - in stock. Delivery time on request
