Pico Probe, differential, PicoConnect 442, 1,000V CATIII for PicoScope 4444, 25: 1, DB9 connector | PQ087

Manufacturer number: PQ087

Pico PQ087 | Differential probe, PicoConnect 442, 10 MHz bandwidth, 1000V CATIII for PicoScope 4444 oscilloscopes, 25: 1, DB9 connector.

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Description

Probe, differential, PicoConnect 442, 1,000V CATIII for PicoScope 4444, 25: 1, DB9 connector | PQ087

The PicoConnect 442 is a passive differential voltage measurement probe with 25: 1 attenuation and 10 MHz bandwidth. It is rated for use up to 1000 V CAT III, and using this probe with the PicoScope 4444 is the most cost-effective way to make these measurements safely on multiple channels. With no need for a battery pack, the PicoConnect 442 is suitable for short- and longer-term voltage measurements. Its powered and connected to the PicoScope 4444 via the D9 connector which is automatically identified by PicoScope software. The probe is double-insulated to eliminate the need for a safety ground. It is fitted with shrouded 4 mm banana leads and comes with a selection of suitable test probes.Applications for this probe include testing the equipment listed for Overvoltage Category III under EN 61010-1: 2010, such as measuring voltages on distribution boards, circuit breakers , and fixed socket outlets.

Key Features & Specifications:

  • Lowest cost per channel method of making 1000 V CAT III measurements safely.
  • Probe is powered and identified by the scope
  • Probe is double insulated to avoid the need for a safety round
  • Uses industry standard shrouded 4 mm 'banana' style leads for use with many compatible test probes.

Applications:

  • Single phase voltage, current and power quality monitoring and analysis up to 1000 V CAT III environments.
  • 3 Phase voltage analysis. Also power analysis with addition of compatible current probes
  • Industrial equipment, motor controllers, power control, power supplies.

Accessoires (4 products )

Accessoires (4 products )

Pico PicoScope 4444 standard kit
USB oscilloscope 4444 incl. 3 x PicoConnect 441 & 1 x TA271 (PQ073)
Delivery time upon request
€1,545.00
Pico PicoScope 4444 1000 V CAT III kit
USB oscilloscope 4444 incl. 3x PicoConnect 442 & 1x TA271 (PQ074)
Delivery time upon request
€1,935.00
Pico PicoScope 4444
USB oscilloscope, differential, 4-channel, 20 MHz, SUB-D9 sockets (PQ088)
Delivery time upon request
€1,295.00
Pico PQ167
Picoscope 4444, 1000V voltage and current set
Delivery time upon request
On Request

About the Manufacturer

Pico
Pico Technology, the leader in USB oscilloscope technology, offers innovative, high-quality and affordable alternatives to traditional benchtop meters. The wide range of PC-based digital oscilloscopes offers a full range of functions. The Pico data loggers are ideal for measuring and storing temperature, humidity, current and voltage.
