NI 782835-37 | PXIe-2737, PXI matrix switch with 256 crosspoints, electromechanical relay (2 A, 100 V)

Manufacturer number: 782835-37

782835-37
Delivery time upon request

€5,120.00

plus VAT. €6,092.80 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description

782835-37 | PXIe-2737, PXI matrix switch with 256 crosspoints, electromechanical relay (2 A, 100 V).

Technical Data

Documents & Downloads

Catalog
pdf | 2.54 MB
Brochure
pdf | 2.74 MB
Overview
pdf | 1.35 MB
Configuration guide
pdf | 1.88 MB

Description

782835-37 | PXIe-2737, PXI matrix switch with 256 crosspoints, electromechanical relay (2 A, 100 V)

The PXIe ‑ 2737 is a 4x64 matrix switch with high channel density that is suitable for routing signals in automated test systems and has electromechanical relays for instantaneous switching. The module also has functions for monitoring distributed systems and planning predictive maintenance, including counting of switching operations, temperature sensors and relay self-checking by the NI Switch Health Center.

Product features:

  • Bus type: PXIe
  • Mode (n-wire): 2-wire
  • Crosspoints: 256
  • Number of banks: 1
  • Number of rows: 4
  • Number of columns: 64
  • Maximum switching voltage (DC): 100 V
  • Maximum switching current (DC): 2 A.
  • Relay type: electromechanical
  • Switching bandwidth: 10 MHz
  • Scanning frequency: 1000 cycles / s
