NI 779680-03 | NI-9234, sound and vibration measurement module of the C series with 4 channels, 51.2 kS / s, IEPE, AC / DC, protective coating

Name: 779680-03 | NI-9234, sound and vibration measurement module of the C series with 4 channels, 51.2 kS / s, IEPE, AC / DC, protective coating
Brand: NI
SKU: 779680-03
Price: 3790.0 EUR
Availability: OutOfStock

Manufacturer number: 779680-03

Delivery time upon request

€3,790.00

plus VAT. €4,510.10 VAT plus shipping costs

or choose one of the following options:

Product inquiries

779680-03 | NI-9234, sound and vibration measurement module of the C series with 4 channels, 51.2 kS / s, IEPE, AC / DC, protective coating.

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Analogue input isolation:	Ohne, nan
Bustype:	C Series
Connection type front:	1-Pin, Weiblich BNC
IEPE excitation (mA):	2
Max. Number of differential analogue input channels:	4
Measured electrical signal:	Voltage
Measurements per second/sampling rate (MS/s):	0.0512
Module width:	1
Protectively coated:	Yes
Resolution of the analogue input:	24 bit
Samplerate:	51.2 kS/s pro Kanal
Voltage measuring range of the analogue input (V):	-5 V bis 5 V
With case:	Yes

Description

779680-03 | NI-9234, sound and vibration measurement module of the C series with 4 channels, 51.2 kS / s, IEPE, AC / DC, protective coating

The NI ‑ 9234 module is suitable for industrial measurements with IEPE (Integrated Electronic Piezoelectric) and non-IEPE sensors such as accelerometers, tachometers and proximity sensors. The module is also compatible with intelligent TEDS sensors. It offers a large dynamic range and enables software-selectable AC / DC coupling and IEPE signal processing. Signals are measured simultaneously on the input channels. All channels also have anti-aliasing filters that are automatically adjusted to the sample rate. When used with National Instruments software, this module provides condition monitoring processing functions such as frequency and order analysis.

Product features:

Maximum number of differential analog input channels: 4
Maximum sampling rate: 51.2 kS / s per channel
Voltage measuring range of the analog input: -5 V to 5 V.
Isolation of the analog input: none
IEPE excitation: 2 mA
Connection type front: BNC (qty 4)
Protective coating: yes
With housing: yes
Supported hardware platform: CompactDAQ, CompactRIO
