Keysight RP7942A | Regenerative Power System, 80V, +/-125A, 5kW, 400/480VAC

Manufacturer number: RP7942A

Keysight RP7942A
Keysight RP7942A
Keysight RP7942A
Keysight RP7942A
Keysight RP7942A
Keysight RP7942A
Keysight RP7942A
Keysight RP7942A
Delivery time upon request

On Request

or choose one of the following options:
Product downloads Product inquiries Request education-price
Highlights Documents / Downloads Description Related Articles

Keysight RP7942A | Programmable, regenerative laboratory power supply, 0 ... 80 V, 0 ... ±125 A, 0 ... 5 kW, input 400 - 480 VAC.

  • Voltage Source: 0 to 80V DC
  • Current source and sink: 0 to ±125A
  • Power: 0 to 5 kW
  • AC input: 400 to 480 VAC
  • Transition-free 2-quadrant mode as power source and regenerative electronic load
  • Autoranging: “more current with reduced output voltage”
  • Optimal control behavior under all load conditions (voltage and current priority)
  • Fastest control behavior with transient load changes of 400 µs
  • Adjustable edge steepness
  • Built-in arbitrary function generator
  • High-precision measurement functions including Ah and Wh measurement
  • Interfaces: GPIB, Ethernet/LAN (LXI), USB 2.0
  • Dimension: (W x H x D) 427 x 132.6 x 763 mm

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Datasheet
pdf | 2.16 MB

Description

RP7942A | Regenerative Power System, 80V, +/-125A, 5kW, 400/480VAC

The bidirectional Keysight DC power supply RP7942A combines powerful DC power source and regenerative electronic load in one device (2-quadrant mode). Its integrated security functions protect both the user and the test subject. The excess energy emitted by the test object can be fed back into the utility network with little loss, thereby reducing energy costs for power consumption and cooling.

The RP7900A series renewable energy system can continuously lower up to 100% of its rated current indefinitely. The transitions between source and sink current occur seamlessly and without changing the output behavior.

Use the RP7942A power system as a power source or as an electronic load:

  • Continuous 2-quadrant operation as power source and sink
  • Autoranging for maximum flexibility
  • Integrated arbitrary function generator for simulating transients
  • Reducing cooling and energy costs through regenerative design
