The Keysight PZ2100 Series High-Resolution Source/Measure Unit (SMU) PZ2110A is a module for the PZ2100A mainframe.
- 10 fA resolution with 30 fArms noise (1 PLC)
- 20 μs pulse width
- Fast digitizer mode with a sampling rate of up to 1.25 MSa/s
- Fast transient response with 1.4V/μs slew rate
In addition to the module presented here, the Keysight PZ2100 series has other modules:
- PZ2120A High-Speed SMU with 1 MSa/s, 100 fA, 60 V, 3.5 A DC/10.5 A pulse
- PZ2121A High-Speed SMU with 15 MSa/s, 100 fA, 60 V, 3.5 A DC/10.5 A pulse
- PZ2130A 5 Channel Precision SMU with 100pA, 30V, 500mA DC
- PZ2131A 5 channel Precision SMU with 500 kSa/s, 10 pA, 30 V, 500 mA DC/pulse
