A 4 GHz 7/16 interface T-calibration kits with open / short / load design for use on-site and for factory production testing.
This calibration set is not suitable for an annual recalibration.
Key Features & Specifications:
- Frequency range: DC to 6 GHz
- Input power: +25 dBm max
- Source match: ≥ 35 dB
- Directivity: ≥ 42 dB
- Impendence: 50 Ω
Open specifications:
- Female offset length: 21,287 mm
- Phase tolerance: 1.25 degrees
- RL: ≤ 0.10 dB
Load specifications:
- DC resistance: 50 Ω ± 0.5 Ω
- RL: ≥ 42 dB
Short specifications:
- Female offset length: 21,287 mm
- Phase tolerance: 0.85 degrees
- RL: ≤ 0.10 dB
