Keysight N8739A | Power supply unit, DC, 1 channel 100V / 33A, 3300W, analog

Manufacturer number: N8739A

N8739A
N8739A
N8739A
N8739A
N8739A
N8739A
N8739A
N8739A
N8739A
2 in stock. Ready to ship in 1 business day

On Request

or choose one of the following options:
Request a quote Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Scope Related Articles

Keysight N8739A | 1-channel power supply, 0 to 100 V / 0 to 33 A DC in one housing with two height units.

  • Power 3300 W.
  • switch-regulated power supply
  • Output voltage 0 to 100 V.
  • Residual ripple voltage 25 mVrms
  • Output current 0 to 33 A.
  • Ripple current 70 mArms
  • Constant voltage operation (CV)
  • Constant current operation (CC)
  • Surge protection (OVP)
  • Overcurrent protection (OCP)
  • Undervoltage limit (OVL)
  • Off / on switch of output
  • Sense
  • USB interface
  • GPIB interface
  • LAN interface
  • Analog interface
  • LXI Class C compatible
  • Built-in web server for remote control
  • Mains voltage input with screw terminals
  • Mains voltage input depending on option 1 or 3 phases (must be selected when ordering)
  • Serial operation (max. 2 devices)
  • Parallel operation (max. 4 devices)
  • 6 Device settings memory
  • Programming commands compatible with Sorensen DLM and Xantrex XFR power supplies
  • Dimensions: W422.8 x D432.8 x H88mm (19inch - 2U)
  • Weight: 13.0 kg
  • Warranty: 3 years

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Datasheet
pdf | 1.08 MB
Userguide
pdf | 3.07 MB

Description

N8739A | Power supply unit, DC, 1 channel 100V / 33A, 3300W, analog

With the power supply series N8700A, Keysight (formerly Agilent's electronic measurement technology) offers DC power supplies with very high performance in a perfect price-performance ratio with a height of only two height units (2U).

The N8700A power supplies are single-channel, computer-controlled laboratory power supplies for universal use in research, development, testing, production, test systems, test equipment construction, system manufacture, training.

Thanks to the extensive protective functions, the connected device under test cannot be damaged even under adverse conditions.

For integration into test benches and remote control applications using a PC, the N8700A power supply can be controlled via the standard USB, GPIB or LAN interface.

The N8700A is fully LXI compatible and also offers an integrated web server for remote control via LAN.

Note:

When you purchase this new device, you will now receive a "Node-Locked" license for the Keysight measurement and analysis app BenchVue for power supplies BV0003B free of charge . This is limited to the specific device. The license is not limited in time.

On the Keysight website you will find further information on downloading, registering and activating your BenchVue license: To the Keysight website.

Lieferumfang

  • Power supply unit N8739A
  • Installation material for mains connection (screw terminals, strain relief, ..)
  • Documentation (user manual) on CD

Available options:

  • N5740A 19 inch rack mount kit for N8739A
  • N8739A-230 mains input 1 phase (220 - 240 V / 50 - 60 Hz) for Europe
  • N8739A-400 Mains input 3 phases (360 - 440 V / 50 - 60 Hz) for Europe
  • N8739A-208 3-phase mains input (180 - 235 V / 50 - 60 Hz) for USA
  • further input voltage options on request
