Keysight N8482H | Power Sensor - Thermocouple, average, 100 KHz to 6 GHz

Manufacturer number: N8482H

Keysight N8482H
Delivery time upon request

On Request

or choose one of the following options:
Product downloads Product inquiries
Highlights Documents / Downloads Description Related Articles

Keysight N8482H | HF power meter with thermocouple, 100 kHz to 6 GHz.

  • Frequency range: 100 kHz to 6 GHz
  • Dynamic power measurement range: -10 dBm (100 μW) to +35 dBm (3.1 W)
  • High accuracy of 1% and low noise <11.4 μW (maximum value)
  • Linearity: from +17 to <+30 dBm: ± 0.77% and from +30 to +35 dBm: ± 2.84%
  • Very good standing wave ratio (SWR / Standing Wave Ratio): 1.13
  • Wide dynamic range covered by a measuring head
  • RF connector: Type N
  • Automatic readout of the calibration data and corresponding correction factors from the EEPROM. The traceability of the performance measurement to the NIST standard (US National Institute of Standard and Technology) is given.
  • Compatibility of this measuring head with the family power meters:
    P series (N1911A / 12A),
    EPM-P series (E4416A / 17A) and
    EPM series (N1913A / 14A, E4418B / 19B)
  • Weight: 0.183 kg
  • Dimensions: 38mm (W) x 30mm (H) x 174mm (L)
  • Warranty 1 year

Options:

  • N8482H - Option CFT offers full SCPI code compatibility of the N8455A power sensor with those of the 8480A series. With this option, the calibration values and correction factors are attached to the outside of a label; no EEPROM

Note: All power sensors of the N8480 series are not compatible with the measuring devices 43x, E1416A, N8262A, with the microwave counters 5314x and with the base station test set E7495x

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Datasheet
pdf | 1.55 MB

Description

N8482H | Power Sensor - Thermocouple, average, 100 KHz to 6 GHz

The N848xA series of HF power meters is based on thermocouples and is one of the most accurate and fail-safe measuring heads that Keysight (formerly Agilents electronic measuring technology) has to offer. What makes them special is that the calibration factors are stored in an EEPROM. This eliminates the need to enter these calibration values into the power meter used before a measurement. The measuring device can read these values directly from the EEPROM. Furthermore, these measuring heads offer an extended frequency range and further power measuring ranges.
