Keysight N6710C | Modular power supply system, 400 W, basic device

Manufacturer number: N6710C

Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Keysight N6710C
Delivery time upon request

€3,433.00

plus VAT. €4,085.27 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries % Additional offers for this product
Highlights Technical Data Documents / Downloads Description Scope Related Articles

Keysight N6710C | MPS basic device / mainframe for up to 4 DC power supply modules max. 400 W. Build-to-order system. Completely configured and tested with the ordered modules.

  • modular structure, max. 4 DC power supply modules possible
  • maximum output power 400W for all outputs together
  • over 30 DC power modules up to max. 150V / 50A available
  • 4 outputs with fine sensing (sense) for supplying the device under test
  • Parallel / serial connection of the outputs possible
  • Possibility of reading back current and voltage (integrated in the power supply modules)
  • Device settings memory
  • Sequence programming for outputs
  • Synchronization to other measuring devices via trigger inputs and outputs
  • Protection functions can be set for all outputs (overvoltage, overcurrent and overtemperature protection)
  • Off / on switch for outputs (optional for the individual DC power modules)
  • Temperature controlled fan
  • Interfaces: USB 2.0, GPIB interface, LAN interface
  • LXI Class C compatible
  • Built-in web server for remote control
  • Dimensions: W432.5 x D 549.7 x H44.45 mm (19 inches - 1U)
  • Weight with 4 DC power supply modules: 12.73 kg
  • Warranty: 3 years

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Brochure
pdf | 0.57 MB
Datasheet
pdf | 0.81 MB
Userguide
pdf | 1.95 MB
Configuration guide
pdf | 1.46 MB

Description

N6710C | Modular power supply system, 400 W, basic device

The MPS (Modular Power System) power supply series N6700C from Keysight (formerly Agilent's electronic measurement technology) is a modularly expandable power supply with a height of just one height unit for diverse applications in laboratory and production environments. Due to the large selection of different power supply modules, the N6700C modular power supply is ideally adaptable to any user application.

For integration into test benches and remote control applications using a PC, the N6700 power supply can be controlled via the standard USB, GPIB or LAN interface. The N6700 is fully LXI compatible and also offers an integrated web server for remote control via LAN.

Lieferumfang

  • MPS basic device N6700C (without DC power supply modules)
  • Power cord
  • Documentation (user manual) on CD
  • Assembly tool for DC power modules

Possible DC modules for this basic device:

  • Basic modules, characteristics and performance data:
    Switching of measured values between voltage or current
    - Output power up to 300 W, module output voltage up to 150 V.
    - Voltmeter accuracy 0.1% +20 mV, ammeter accuracy 0.15% +2 mA
    - Modulation of the output voltage up to 260 Hz
  • High performance modules , characteristic and performance data:
    Simultaneous display of output voltage, current and power
    - Output power up to 500 W, module output voltage up to 60 V.
    - Voltmeter accuracy 0.05% +10 mV, ammeter accuracy 0.1% +4 mA
    - Modulation of the output voltage up to 4 kHz
  • Precision modules , characteristics and performance data:
    Simultaneous display of output voltage, current and power
    - Output power up to 500 W, module output voltage up to 60 V.
    - Voltmeter accuracy 0.016% +1.5 mV, ammeter accuracy 0.05% +100 nA (with option 2UA)
    - Modulation of the output voltage up to 4.5 kHz
  • SMU modules, (source / measure unit) characteristic and performance data:
    Display of output voltage, current and power
    - Output power up to 20 W, module output voltage ± 20 V, module output current ± 3 A
    - Voltmeter accuracy 0.025% +50 µV, ammeter accuracy 0.025% +8 nA
    - Modulation of the output voltage up to 100 kHz
  • Application-specific modules, one module specifically for measuring batteries , the other for testing mobile, battery-powered mobile devices ; Characteristics and performance data:
    Display of output voltage, current and power
    - Output power up to 24 W, module output voltage up to 8 V, module output current -2 to +3 A.
    - Voltmeter accuracy 0.05% + 5 mV, ammeter accuracy 0.1% + 75µA
    - Operation in 2 quadrants
