Keysight N2889A | Probe, passive 10X / 1X, 350 / 10MHz, 1.3m, BNC

Manufacturer number: N2889A

Keysight N2889A
Delivery time upon request

€212.00

plus VAT. €252.28 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries
Highlights Technical Data Documents / Downloads Description Related Articles

Keysight (formerly Agilent's electronic measurement technology) N2889A - Passive probe with 10 MHz / 350 MHz bandwidth, 10: 1/1: 1 divider and BNC connector.

  • Bandwidth: 350 MHz (in 10: 1 attenuator mode) and up to 10 MHz (in 1: 1 attenuator mode)
  • Rise time: 1 ns at 10: 1 and 35 ns at 1: 1 (pulse edge 10% - 90%)
  • Attenuator 10: 1 or 1: 1 switchable
  • Input resistance 10 MΩ (at 10: 1) or 1 MΩ (at 1: 1 if the oscilloscope has an input impedance of 1 MΩ)
  • Input capacitance: 11 pF (at 10: 1) and 60 pF (at 1: 1)
  • Compensation range of the oscilloscope input capacitance: 5 to 30 pF (at 10: 1)
  • Maximum input voltage: 300 VRMS (or> 400Vpk) CAT I / II (@ 10: 1), 150 V RMS CAT I / II (@ 1: 1)
  • Connection BNC connector
  • Cable length: 1.3 m
  • Can be used with all oscilloscopes with BNC socket and an input capacitance from 5 to 30 pF and the Keysight (formerly Agilents electronic measurement technology) oscilloscopes of the series 1000, 2000X, 3000X, 3000, 4000x, 5000, 6000, 7000, 8000, 9000

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Overview
pdf | 5.13 MB
Datasheet
pdf | 0.88 MB

Description

N2889A | Probe, passive 10X / 1X, 350 / 10MHz, 1.3m, BNC

The Keysight N2889A (formerly Agilent's electronic measurement technology) is an inexpensive probe with a bandwidth of 350 MHz and a high input resistance of 10 MΩ (in 10: 1 attenuator mode) in order to introduce the lowest possible load at the measuring point. The attenuator ratio can be switched from 1: 1 or 10: 1 using a switch in the sample head.

The probe compensation can be tuned to either high or low frequencies. For the best measurement results, the probe should be matched to the respective oscilloscope.
This probe can be used on all oscilloscopes with an input capacitance of: 5 to 30 pF.
The probe is intended for general applications.
