Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz | MSOX2022A

Manufacturer number: MSOX2022A

Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
Keysight Oscilloscope, MSO, 2 + 8-channel, 200 MHz
11 in stock. Ready to ship in 1 business day

€4,396.00

plus VAT. €5,231.24 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Scope Related Articles

Keysight MSOX2022A | 2-channel mixed-signal oscilloscope (digital storage oscilloscope and 8-channel logic analyzer) with a bandwidth of 200 MHz, up to 2 GS / s sampling rate and a signal acquisition rate of 200,000 signals / s.

  • 2 analog and 8 digital inputs
  • Bandwidth 200MHz
  • Sampling rate 1 GS / s per channel, 2 GS / s with half the number of channels (interleaved)
  • Storage depth up to 1 megapoint standard
  • MegaZoom IV memory and display technology for fast navigation and signal analysis
  • Highest signal acquisition rate of 200,000 signals / s for the safe acquisition of rare events
  • Real-time signal acquisition
  • Integrated segmented memory for capturing 250 segments (formerly option DSOX2SGM)
  • Vertical resolution 8 bit / up to 12 bit in high resolution mode
  • 25 automatic measurement functions
  • Powerful trigger options as well as extended trigger options from Edge then Edge, Runt, Setup and Hold, Rise / Fall Time, Nth Edge Burst and Or triggers (as with the 3000A X models)
  • Various math functions as well as advanced math functions from Ax + B, Square, Absolute Value, Log, Log (e), Exponential, Exp (10), LPF, HPF, Magnify, Measurement Trend, Logic Bus Chart (as with the 3000A X models)
  • FFT with 64k measuring points
  • Standard built-in 3 digit digital voltmeter and 5 digit frequency counter (DSOXDVM)
  • Integrated Education Training Kit (DSOXEDK)
  • Brilliant 21.6 cm color wide screen in WVGA (800 x 480px) resolution
  • Adjustable persistence: Off, infinite, variable (100ms - 60s)
  • 64 brightness levels to show the frequency of signal details
  • "Push buttons" and direct menu buttons for quick and intuitive operation
  • Multilingual menu navigation / online help in German, English, Italian, Spanish, French etc.
  • Whisper-quiet operation for relaxed and concentrated work.
  • USB 2.0 high-speed device port on the rear panel
  • One USB 2.0 high-speed host port on the front panel and one on the rear panel (supports memory sticks and printer)
  • Storage of setup files / settings
  • Save signal data and / or transfer to PC of signal data in * .csv
  • Save and / or transfer screenshots to PC in 8/24 bit * .bmp and 24 bit * .png
  • Intuilink SW / Toolbars for fast processing of the data in Microsoft Word / Excel
  • Housing dimensions: W 380.6 x H 204.4 x D 141.5 mm
  • Weight 3.85 kg
  • Connection 100-240 V AC, 50/60 Hz, 100 W max.
  • Warranty: 5 years

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Datasheet
pdf | 3.57 MB
Userguide
pdf | 6.79 MB

Description

Oscilloscope, MSO, 2 + 8-channel, 200 MHz | MSOX2022A

The oscilloscope redefined: more oscilloscopes for the same money - thanks to revolutionary technology. The Keysight (formerly Agilent's electronic measurement technology) InfiniiVision 2000 X-Series oscilloscopes offer features and upgrade options that you won't find in any other oscilloscope in this price range. These oscilloscopes offer a large screen , large memory and the highest signal update rate in this class.

These oscilloscopes are unusually versatile because they combine the functions of several measuring devices: oscilloscope, logic timing analyzer and WaveGen function generator (optional). Your investment is optimally protected: all models can be upgraded. The ideal oscilloscopes for use in training / education / laboratory / development / production.

Note:

When you purchase this new device, you will now receive a “Node-Locked” license for the Keysight measurement and analysis app BenchVue for oscilloscopes BV0004B free of charge . This is limited to the specific device. The license is not limited in time.

On the Keysight website you will find further information on downloading, registering and activating your BenchVue license: To the Keysight website.

Lieferumfang

  • 1 x 2000 X mixed-signal oscilloscope
  • 2 x passive probes including accessories
  • 8 channel logic probe including accessories for contacting
  • Documentation (user manual) on CD
  • Power cord
  • Traceable calibration certificate

Accessoires (16 products )

Keysight BV9001B
Keysight BV9001B
BenchVue full version, PC measurement and evaluation software
Ready to ship in 5 to 10 business days
On Request
Keysight DSOX2WAVEGEN
Keysight DSOX2WAVEGEN
Function generator option, 20 MHz, 1-channel, for 2000 X oscilloscopes
Ready to ship in 5 to 10 business days
€672.00
Keysight DSOXEDK
Keysight DSOXEDK
Training Kit Education for X Series 2/3/3/4 / 6000A & 3000T, retrofit option EDK
Ready to ship in 5 to 10 business days
€460.00
Keysight N6456A
Keysight N6456A
Rackmount kit for X2000A and X3000A / T series
4 in stock. Ready to ship in 1 business day
€457.00
Keysight N6457A
Keysight N6457A
Carrying case with front cover for oscilloscope X2000A and X3000A / T series
Delivery time upon request
€196.00
Keysight DSOXLAN
Keysight DSOXLAN
VGA / LAN module for X2000A / X3000A / T series / retrofitting (option 805)
8 in stock. Ready to ship in 1 business day
€266.00
Keysight DSOXGPIB
Keysight DSOXGPIB
GPIB module for X2000A / X3000A / T series / retrofitting (option 806)
2 in stock. Ready to ship in 1 business day
€672.00
TTI I-PROBER520
TTI I-PROBER520
Probe / current probe, 10 mA to 20 A, DC - 5 MHz, BNC
1 in stock. Ready to ship in 1 business day
On Request
Pico TA058
Pico TA058
Probe, differential 10: 1, 50 MHz, ± 700V, BNC
Delivery time upon request
€469.00
Pico TA044
Pico TA044
Probe, differential, high voltage 100X / 1000X, 70MHz, ± 7000V, BNC
2 in stock. Ready to ship in 1 business day
€909.00
Pico TA042
Pico TA042
Probe, differential 100X / 1000X, 100MHz, 1400V, BNC
Delivery time upon request
€609.00
Keysight DSOX2PLUS
Keysight DSOX2PLUS
Upgrade option for your 2000 X oscilloscope
Ready to ship in 5 to 10 business days
€303.00
Keysight MSOX2022A-A6J
Keysight MSOX2022A-A6J
Calibration according to ANSI Z540
Delivery time upon request
€138.00
Keysight U1881A
Keysight U1881A
Software performance analysis for oscilloscope X3 / 4/6 / 7xxx series
Delivery time upon request
€1,653.00
Rohde&Schwarz RT-ZP03S
Rohde&Schwarz RT-ZP03S
Probe, passive, 10: 1, 300 MHz, 400 V, 1.2 m, BNC (1803.1001.02)
Delivery time upon request
€90.00
Chauvin Arnoux MX9030-Z
Chauvin Arnoux MX9030-Z
Probe, differential, high voltage 20X / 200X, 30MHz, 1.2kV
Delivery time upon request
€454.00

Alternate products (9 products )

Keysight Oscilloscope, MSO, 4 + 8-channel, 70 MHz
Serie
Keysight Oscilloscope, MSO, 4 + 8-channel, 70 MHz
MSOX2004A
6 in stock. Ready to ship in 1 business day
€3,944.00
Keysight Oscilloscope, MSO, 4 + 8-channel, 200 MHz
Serie
Keysight Oscilloscope, MSO, 4 + 8-channel, 200 MHz
MSOX2024A
Delivery time upon request
€5,165.00
Rohde&Schwarz RTB2K-102
Serie
Rohde&Schwarz RTB2K-102
Oscilloscope, RTB2000 series, DSO, 2-channel, 100 MHz, 10 bit, 10 (20) Mpts. (1333.1005P12)
Delivery time upon request
€2,050.00
Rohde&Schwarz RTB2K-72
Serie
Rohde&Schwarz RTB2K-72
RTB2002 Oscilloscope, RTB2000 Series, DSO, 2-Channel, 70 MHz, 10 Bit, 10 (20) Mpts (1333.1005P02)
Delivery time upon request
€1,640.00
Rohde&Schwarz RTB2K-202M
Serie
Rohde&Schwarz RTB2K-202M
Oscilloscope, RTB2000 series, MSO, 2+16-channel, 200 MHz, 10 bit, 10 (20) Mpts. (1333.1005P23)
Delivery time upon request
€3,760.00
Rohde&Schwarz RTB2K-COM2
Bundle
Rohde&Schwarz RTB2K-COM2
Complete package including oscilloscope RTB2002, MSO, 2+16-channel, 300 MHz & APP bundle RTB-PK1 (1333.1005P97)
Delivery time upon request
€6,130.00
Rohde&Schwarz RTB2K-302M
Serie
Rohde&Schwarz RTB2K-302M
Oscilloscope, RTB2000 series, MSO, 2+16-channel, 300 MHz, 10 bit, 10 (20) Mpts. (1333.1005P33)
Delivery time upon request
€4,880.00
Rohde&Schwarz RTB2K-202
Serie
Rohde&Schwarz RTB2K-202
Oscilloscope, RTB2000 series, DSO, 2-channel, 200 MHz, 10 bit, 10 (20) Mpts. (1333.1005P22)
Delivery time upon request
€2,880.00
Rohde&Schwarz RTB2K-102M
Serie
Rohde&Schwarz RTB2K-102M
Oscilloscope, RTB2000 series, MSO, 2+16-channel, 100 MHz, 10 bit, 10 (20) Mpts. (1333.1005P13)
Delivery time upon request
€3,010.00

Recommendations (24 products )

Keysight U1233A
Keysight U1233A
Multimeter, TRMS, 4 digits, IP42, DCI / ACI, temperature
Delivery time upon request
€381.00
Keysight BV0004B
Keysight BV0004B
BenchVue Oscilloscope App PC measurement and evaluation software
Ready to ship in 5 to 10 business days
On Request
Keysight U1242B
Keysight U1242B
Multimeter, TRMS, 4 digits, ACV / DCV, type K / J, data logging
5 in stock. Ready to ship in 1 business day
€427.00
Keysight U1253B
Keysight U1253B
Multimeter, TRMS, 4½, OLED, ACV / DCV, integr. Rectangle generator
Delivery time upon request
€868.00
Keysight 34460A Truevolt Series
Serie
Keysight 34460A Truevolt Series
Bench Multimeter, TRMS, 6 ½ digits, Truevolt (344xxA)
2 in stock. Ready to ship in 1 business day
€1,177.00
Weller T0053442699N
Weller T0053442699N
WT1014 soldering station set, 1-channel, 90 W with soldering iron WSP80, soldering tip & safety rest
Delivery time upon request
€430.00
Weller T0053640299N
Weller T0053640299N
WFE direct suction
Delivery time upon request
€715.00
Erem 3600KU
Erem 3600KU
Universal tool set, 11-part tool set
Delivery time upon request
€391.00
Keysight 34450A Truevolt Series
Keysight 34450A Truevolt Series
Benchtop Multimeter, TRMS, 5 ½ digits, OLED
5 in stock. Ready to ship in 1 business day
€1,066.00
GW Instek PSP-405
GW Instek PSP-405
Power supply unit, DC, 1 channel 40V / 5A, 200W, RS232
Reordered - in stock. Delivery time on request
€338.00
GW Instek GPS-4303 DC power supply, 4-channel
GW Instek GPS-4303 DC power supply, 4-channel
3 in stock. Ready to ship in 1 business day
€391.00
GW Instek MFG-2110
GW Instek MFG-2110
Function generator, 1-channel, 10MHz, 10Vss, arbitrary, USB
Delivery time upon request
€396.00
Teledyne FLIR ONE PRO
Teledyne FLIR ONE PRO
Thermal camera for smartphones, Android, USB-C, 160 x 120 px, MSX
Delivery time upon request
€399.00
Keysight N2747A
Keysight N2747A
Front cover oscilloscope for X2000A / X3000A / T series
Delivery time upon request
€62.68
Keysight DSOXGPIB
Keysight DSOXGPIB
GPIB module for X2000A / X3000A / T series / retrofitting (option 806)
2 in stock. Ready to ship in 1 business day
€672.00
Keysight DSOXEDK
Keysight DSOXEDK
Training Kit Education for X Series 2/3/3/4 / 6000A & 3000T, retrofit option EDK
Ready to ship in 5 to 10 business days
€460.00
Keysight N2755A
Keysight N2755A
8 channel MSO cable for X2000A series
Delivery time upon request
€879.00
Keysight DSOXLAN
Keysight DSOXLAN
VGA / LAN module for X2000A / X3000A / T series / retrofitting (option 805)
8 in stock. Ready to ship in 1 business day
€266.00
Keysight N6457A
Keysight N6457A
Carrying case with front cover for oscilloscope X2000A and X3000A / T series
Delivery time upon request
€196.00
FLUKE 62MAX
FLUKE 62MAX
Fluke 62MAX Infrared Thermometer, 10: 1, -30 ° C to 500 ° C, single laser
1 in stock. Ready to ship in 1 business day
On Request
FLUKE 62 MAX +
FLUKE 62 MAX +
Fluke 62MAX + infrared thermometer, 12: 1, -30 ° C to 650 ° C, double laser
Delivery time upon request
On Request
Keysight D2000AUTB
Keysight D2000AUTB
Automotive software for oscilloscopes InfiniiVision 2000 X series
Ready to ship in 5 to 10 business days
€580.00
Keysight D2000GENB
Keysight D2000GENB
Embedded Analysis Software for InfiniiVision 2000 X Series Oscilloscopes
Ready to ship in 5 to 10 business days
€580.00
Keysight D2000BDLB
Bundle
Keysight D2000BDLB
Ultimate software bundle for InfiniiVision 2000 X series oscilloscopes
Delivery time upon request
€869.00

Options (1 product )

Keysight MSOX2022A-A6J
Keysight MSOX2022A-A6J
Calibration according to ANSI Z540
Delivery time upon request
€138.00

Probes (3 products )

Pico TA058
Pico TA058
Probe, differential 10: 1, 50 MHz, ± 700V, BNC
Delivery time upon request
€469.00
Chauvin Arnoux MX9030-Z
Chauvin Arnoux MX9030-Z
Probe, differential, high voltage 20X / 200X, 30MHz, 1.2kV
Delivery time upon request
€454.00
TTI I-PROBER520
TTI I-PROBER520
Probe / current probe, 10 mA to 20 A, DC - 5 MHz, BNC
1 in stock. Ready to ship in 1 business day
On Request

News and Knowledge

Applications
Buyer's Guide - How to choose an oscilloscope.

Navigating through the range of available specifications, options and capabilities can be challenging. There are a lot o...

15/02/2024
Reading time 25 Min.
104
0

About the Manufacturer

Keysight
Keysight
dataTec and Keysight Technologies have had a strong partnership since 1999. No other company offers such a wide range of measurement technology, testing solutions, and solutions for our connected world. With Keysight's measuring instruments, you are also well-equipped for today's and tomorrow's tasks.
Read more

Last Seen Products

Product added to compare
Product Compare added Product Compare
