Keysight EDUX1052G | Oscilloscope, 2 channels, signal generator 50 MHz, 1 GSa / s, 100,000 wfm / s, 200 KPts, USB, LAN

Name: EDUX1052G | Oscilloscope, 2 channels, signal generator 50 MHz, 1 GSa / s, 100,000 wfm / s, 200 KPts, USB, LAN
Brand: Keysight
SKU: EDUX1052G
Availability: InStock

Manufacturer number: EDUX1052G

Delivery time upon request

On Request

or choose one of the following options:

Request a quote Product inquiries Request education-price

Keysight EDUX1052G | InfiniiVision 1000 X series oscilloscope for training and study, 2 channel, 50 MHz bandwidth, sampling rate 1 GSa / s, integr. 20 MHz signal generator.

Analog channels: 2
Bandwidth: 50 MHz
Trigger input can be used as "third channel" with display on screen
Measurement curve update rate: 100.0000 wfms / sec
Max. Sampling rate: 1 GSa / s
Max. Memory depth: 200,000 pts
Integrated automatic signal parameter measurements: 14 amplitude, 14 timing and 4 pulse count measurements, bode plot
Math functions: Add, Subtract, Multiply, Divide, FFT (Magnitude and Phase), Low Pass Filter
Extended trigger options (all typical serial triggers are standard)
Serial protocol analyzer for the standards: ²C, UART / RS-232
Training signals are integrated as standard
Integrated digital voltmeter (DVM)
Integrated frequency counter
Color screen: screen diagonal approx. 18 cm (7.0 inches), TFT LCD WVGA
Interface: USB (host and device), LAN
3 year guarantee

Technical Data

Article number:	EDUX1052G
Bandwidth (MHz):	50
Counter:	Yes
DVM:	Yes
Dimensions (L x W x H) (mm):	130 x 314 x 165
Function generator:	20 MHz
Interfaces:	USB, LAN
Model:	EDUX1052G
Number of channels:	2
Number of digital channels:	1
Samplerate:	1 GSa/s
Screen size:	17,8 cm
Screen type:	WVGA TFT LCD
Signal acquisition rate:	100.000 wfms/s
Special features:	Bode plot
Storage depth:	200 kPts
Triggertypes:	Edge, Pulse width, Video, I²C, RS-232/422/485/UART
Vertical resolution:	8-bit
Warranty (years):	3
Weight (kg):	3.23

Description

EDUX1052G | Oscilloscope, 2 channels, signal generator 50 MHz, 1 GSa / s, 100,000 wfm / s, 200 KPts, USB, LAN

The Keysight EDUX series oscilloscopes are based on the Keysight 1000 X series oscilloscopes. Using the same technology as the Keysight high-end oscilloscopes, the 1000 X-Series enables students to learn on the same hardware and software used in leading R&D departments.

Each device has measurement options and software-based analyzes, which enable you to carry out professional measurements and gain specialist knowledge in training and studies. Offer your pupils and students high-quality training and prepare them for the future with professional instruments.

The EDUX1052G variant has 2 analog channels, a bandwidth of 50 MHz, a sampling rate of 1 GSa / s and an integrated 20 MHz function generator. Alternatively, you can get the Keysight EDUX oscilloscope of the 1000 X series without function generator (EDUX1052A).

Product features:

Integrated training signals that allow students to quickly learn to capture and analyze signals.
The resource kit for instructors and teachers includes dynamic teaching laboratories, comprehensive laboratory instructions, a tutorial written specifically for students and a PowerPoint slide set with the basics of the oscilloscope for professors and laboratory assistants.
Course documents specially developed for IoT systems.
Bode plots are basic concepts. The frequency response analyzer function of the 1000 X series is the perfect tool to help students understand the gain and phase performance of passive RLC circuits or active operational amplifiers.
With the BenchVue software with the BV0004B BenchVue oscilloscope app (standard) you can control and visualize the 1000X series and several measurements at the same time.

Lieferumfang

oscilloscope
2 passive probes N2142A
Power cord
Calibration certificate
