Keysight N6705C | Stock sale - Modular 4-channel power supply & DC power analyzer, 600 W, mainframe (DT2382_2301_L)

Name: N6705C | Stock sale - Modular 4-channel power supply & DC power analyzer, 600 W, mainframe (DT2382_2301_L)
Brand: Keysight
SKU: DT2382_2301_L
Availability: InStock

Manufacturer number: DT2382_2301_L

2 in stock. Ready to ship in 1 business day

On Request

or choose one of the following options:

Product inquiries

Special item - Keysight N6705C | Modular 4-in1 complete solution with 4-channel power supply with max. 600 watts and integrated DC power analyzer.

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Special item type:	Stock sale

Description

N6705C | Stock sale - Modular 4-channel power supply & DC power analyzer, 600 W, mainframe (DT2382_2301_L)

In-depth insights into the power consumption of your test object - without having to assemble a complex test system: The basic device N6705C Black-Edition of the N6700C family, designed for development, service and also production, accommodates a total of up to 4 progr. DC power supply modules with multimeter, oscilloscope, arbitrary waveform generator and data logger functions, with a total output power of 600 W. The output voltages of these 4 power modules can be set independently of each other via the front panel and without the need for programming or a PC.

Digital multimeter functions for voltages and currents, arbitrary function of the output variables, oscilloscope and data logger functionality make the system as a whole a universal source with integrated measurement functions that helps you to test your DUT (device under test) quickly and accurately.

Typical applications for the N6705C:

Power consumption when switching a DUT on and off
Very important nowadays: Checking software to ensure that a mobile device is not switched on and off continuously and unnoticed. This may increase the operating time of a mobile device Significantly
Measure the time-dependent voltage and current parameters of your DUT
Evaluate the switch-on and switch-off behavior of a DC power supply
Generate transients and operating faults of a DC voltage source
Record data in seconds or daily intervals to measure power consumption or detect anomalies
Save data either internally or externally via USB
Save and name test routines for easy repeatability of measurement sequences

Note:

When you purchase this new device, you will immediately receive a "node-locked" license of the Keysight measurement and analysis app BenchVue for power supplies BV0003B free of charge. This license is limited to the specific device. The license is not limited in time.

On the Keysight website you will find further information on downloading, registering and activating your BenchVue license: To the Keysight website.

Please note: Special items / stock sales are unused and in their original packaging. All special items have 1 year warranty. Subject to prior sale. The configuration of a special item cannot be changed. The calibration of a special item may no longer be up to date. If you would like an up-to-date calibration, please contact our experts.

Call us, we will be happy to advise you personally:

+49 (0)7121 / 51 50 50

You can find the current special items list as a PDF download here:

>>> To the dataTec special items list
