Keysight AC6906L | AC power supply AC6900 series, 320 Vrms, 6 kVA, 550 Hz, 3 phase

Name: AC6906L | AC power supply AC6900 series, 320 Vrms, 6 kVA, 550 Hz, 3 phase
Brand: Keysight
SKU: AC6906L
Availability: OutOfStock

Manufacturer number: AC6906L

Delivery time upon request

On Request

or choose one of the following options:

Request a quote Product inquiries

Keysight AC6906L | AC power supply AC6900 series, 320 Vrms, 6 kVA, 550 Hz, 3 phase.

Three-phase AC power supply
Output voltage: 320Vrms
Power: 6kVA
Combines the capabilities of a multimeter, a harmonic analyzer and a power analyzer in one instrument
Can generate direct current alone or as a direct current offset to an alternating current waveform
Can operate in single phase, single phase 3-wire, or three-phase 4-wire, and can operate in both AC, DC, and AC plus DC modes
High accuracy when measuring voltage, current and power
High bandwidth when measuring harmonic distortion
Integrated harmonic generation function
Fanless design to reduce noise and extend the life of the device
Overcurrent protection, overvoltage protection and overheating protection

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

AC input:	1P
AC output:	1P / 3P
Article number:	AC6906L
DC output reversible:	AC Source
Dimensions (L x W x H) (mm):	650 x 445 x 345
Frequency range:	40 Hz - 550 Hz
Grid simulation:	No
Interfaces:	USB-TMC, USB-CDC (Virtual COM), LAN optional: GPIB
Mains feedback:	No
Measurement functions:	Voltage, current, power, AC, DC and AC+DC
Model:	AC6906L
PLD Testfunction:	No
Power factor:	0,95
Protective devices:	OVP, OCP, OTP
Warranty (years):	3
Weight (kg):	49
max. Power (A):	60
max. Voltage (V):	320

Description

AC6906L | AC power supply AC6900 series, 320 Vrms, 6 kVA, 550 Hz, 3 phase

The Keysight AC6906L is a three-phase AC power supply with an output voltage of 320 Vrms and a power of 6 kVA. It is part of the Keysight AC6900 series and offers an all-in-one AC/DC power solution by additionally combining a multimeter, harmonic analyzer and power analyzer in one instrument.

The AC6906L can operate in single-phase, single-phase 3-wire, or three-phase 4-wire, and can operate in AC, DC, or AC plus DC modes.

The Keysight AC6900 Series AC sources are the perfect choice for simplifying test setups, reducing test complexity, and generating accurate and precise data in the shortest possible time. The series offers a choice of single, two or three phase AC power supplies with power ratings up to 18kVA and frequencies up to 5kHz.

The power supply has a variety of features that make it an indispensable tool for engineers and technicians. These include high accuracy when measuring voltage, current and power as well as a high bandwidth when measuring harmonic distortion. Additionally, it also has a built-in harmonics generation feature that allows you to simulate the effects of harmonic distortion on your circuits.

The 5 inch LCD color display enables you to use it intuitively and shows the most important measurements for all phases at the same time. Multiple IO connectivity - LXI-LAN, USB and GPIB - gives you flexible synchronization. Of course, the Keysight AC6906L is equipped with a variety of safety features, including overcurrent protection, overvoltage protection and overheating protection.

Product features:

Output:

Single-phase, single-phase 3-wire or three-phase 4-wire
AC, DC or AC plus DC operation
Maximum AC voltage at 320 Vrms
Maximum DC voltage at 452 V
Frequency up to 5kHz
parallel operation

Integrated tests:

Power grid failure
sequencing
Analysis of harmonics
Integrated waveform generation
