Keysight 53210A | Frequency counter, DC to 350 MHz, 1-channel, 10 digits / s
Manufacturer number: 53210A
Keysight 53210A | 1-channel (opt. 2-K) 350MHz frequency counter.
- Channels: 1 (optional CH 2)
- Measurement resolution 10 digits at 1 s
- Measuring range 0.1 Hz to 350 MHz
- Measuring range K2: 6/15 GHz
- Sensitivity: 20 mVrms at DC to 100 MHz /> 100 MHz: 40 mVrms
- Min. Pulse width: 100 ps
- Measurement resolution (gate time) 1 ms to 1000 s
- Input impedance: 1 MΩ in parallel <25 pF or 50 Ω (switchable) / AC or DC
- Attenuator: Voltage Range: x10 / Trigger Range: x10
- Max. Input voltage 50 Ω: 5 Vrms (50 Vrms) / 500 Vrms with 10: 1 sample
- Measurement functions: Frequency, period, frequency ratio, max / min / peak-to-peak input voltage
- Measured value statistics: current measured value, minimum, maximum, standard deviation
- Options / extensions: 19 "mounting frame, optional channels depending on the model, highly stable time bases etc.
- Interfaces: high-speed USB, LAN, GPIB
- Dimensions: W 261 x H 104 x D 303mm
- Weight: 3.9kg
Technical Data
Article number: | 53210A |
---|---|
Dimensions (L x W x H) (mm): | 303,2 x 261,1 x 103,8 |
Event Count (Totalize): | 300 |
Input impedance: | 1 MΩ parallel <25 pF or 50 Ω (switchable) / AC or DC |
Interfaces: | LAN, USB, GPIB |
Measurement functions: | Frequency, Frequency Ratio A/B, Single Period, TI, Duty, Phase, Totalize, Volts pk-pk |
Measurement resolution (gate time): | 1 ms - 1000 s in 10 µs Schritten |
Measuring range RF (MHz): | 350 |
Measuring resolution: | 10 digits/s |
Messwertstatistik: | current measured value, minimum, maximum, standard deviation |
Min. pulse width: | 100 ps |
Model: | 53210A |
Number of channels: | 1 |
Options/Extensions: | Optional: Kanal 2 (6 GHz / 15 GHz) |
Sensitivity: | 20 mVrms DC bis 100 MHz / > 100 MHz: 40 mVrms |
Trigger source: | Intern, Extern, Bus, Manuel |
Weakening: | Voltage Range: x10 / Trigger Range: x10 |
Weight (kg): | 3.9 |
Documents & Downloads
Description
53210A | Frequency counter, DC to 350 MHz, 1-channel, 10 digits / s
HF and universal frequency counters / timers Frequency counters are responsible for fast, exact frequency and time interval measurements in development and production.
The counter 53210A allows measurements on channel 1 to 350 MHz and optionally with a second channel with 6 or 15 GHz at resolutions up to 10 digits / s and individual measurements with a resolution up to 100 ps. The 4.3 "(11 cm) color display allows the display of graphic trend lines and histograms.
Optional carrier frequency, pulse repetition frequency (PRF), pulse interval repetition and carrier width extend the standard measurements. The "continuous measurement" measurement mode enables modulation analyzes with up to 1 million measured values.
In addition to high measurement accuracy and speed, versatile measurement parameters, the 53200 family of meters also offers flexible results display for quick assessment of the measurement results.
Battery operation is optionally available.
Lieferumfang
- Power cord, user manual, standard time base
- Warranty: 3 years
