Keysight 34906A | 2 GHz 1: 4 HF-Mux, 75 Ohm, module for data logger 34970A / 34972A

Name: 34906A | 2 GHz 1: 4 HF-Mux, 75 Ohm, module for data logger 34970A / 34972A
Brand: Keysight
SKU: 34906A
Price: 1258.0 EUR
Availability: OutOfStock

Manufacturer number: 34906A

Delivery time upon request

€1,258.00

plus VAT. €1,497.02 VAT plus shipping costs

or choose one of the following options:

Product inquiries

Keysight 34906A | Double 4-channel RF multiplexer 75 Ω plug-in module for data logger 34970A / 34972A.

2 banks 1 x 4 switching matrix (75 Ohm)
Scan rate of 60 channels / s
Max. 42 V switching voltage
Max. 0.7 A switching current
Max. 20 W switching power
Max. 2 GHz bandwidth
Warranty 3 years

Independant Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Detaildescription

34906A | 2 GHz 1: 4 HF-Mux, 75 Ohm, module for data logger 34970A / 34972A

The Keysight 34906A module for the 34970A / 34972A measurement data acquisition / switching system is an RF multiplexer (75 ohms) for broadband switching operations and pulse signals. It routes the test signals between the device and a frequency generator, oscilloscope, spectrum analyzer or other instruments.

The RF multiplexer consists of 2 independent 1 x 4 multiplexers. The connections can be made directly via the SMB inputs with 2 GHz bandwidth or via the BNC to SMB adapter cable with a bandwidth of 1 GHz. A connection to the internal DMM of the 34970A / 34972A is not possible.

Lieferumfang

Plug-in card 34906A
10 adapter cables 75 Ohm SMB to BNC connector
Calibration certificate
