Keithley DMM6500 | 6½-digit digital multimeter with 15 measuring functions

Name: DMM6500 | 6½-digit digital multimeter with 15 measuring functions
Brand: Keithley
SKU: DMM6500
Price: 1627.5 EUR
Availability: InStock

Manufacturer number: DMM6500

14 in stock. Ready to ship in 1 business day

€1,627.50

plus VAT. €1,936.72 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price % Additional offers for this product

Keithley DMM6500 | 6½-digit digital multimeter with 15 measuring functions such as capacitance and temperature measurements, 5-inch touchscreen display and many connection options.

Modern touchscreen display: Intuitive operation via a large 5-inch capacitive touchscreen with 6½-digit resolution.
Versatile measurement functions: From capacitance to precise temperature measurements, the DMM6500 covers 15 functions with extended measurement ranges.
High speed digitization: Capture transient events with an integrated 1 MS/s digitizer, ideal for detailed waveform analysis.
Extended calibration intervals: Benefit from a base accuracy of 25 PPM DCV for one year, enabling longer calibration cycles.

Technical Data

2-/4-wire:	2-/4
Accuracy voltage measurement AC:	0,04 %
Accuracy voltage measurement DC:	0,0030 %
Article number:	DMM6500
Capacity measuring range:	1 nF - 100 µF
Current measuring range AC:	100 µA - 10 A
Current measuring range DC:	10 µA - 10 A
Dimensions (L x W x H) (mm):	387,4 x 224 x 107,2
Diode test / continuity test:	Yes / Yes
Display:	5 inch, touchscreen, graphic
Frequency measuring range:	3 Hz - 300 kHz
Interfaces:	USB, LAN, Digital I/O, BNC
Model:	DMM6500
Number of positions:	6.5
Resistance measuring range:	1 Ω - 100 MΩ
Temperature measurement:	Yes
Voltage measuring range AC:	100 mV - 750 V
Warranty (years):	3
Weight (kg):	4.54
max. Measuring range DC (V):	1000
min. Measuring range DC (mV):	100

Description

DMM6500 | 6½-digit digital multimeter with 15 measuring functions

The Keithley DMM6500 is a state-of-the-art laboratory/system digital multimeter. Its outstanding feature is the generous 5-inch 6½-digit touchscreen display that provides intuitive interaction and clear visualization of measurement data. Ideal for both the laboratory and system integration, this DMM ensures precise results across 15 measurement functions, including capacitance and various temperature sensors (RTD, thermistor, thermocouple).

The device features a high-speed 1 MS/s digitizer for capturing voltage or current waveforms, eliminating the need for additional equipment. With its advanced DCV accuracy of 25 PPM for one year, you can extend your calibration intervals and optimize productivity. Equipped with standard USB-TMC, LXI/Ethernet interfaces as well as optional GPIB and RS-232 modules, the DMM6500 adapts seamlessly to various measurement environments.

Designed to meet the demands of modern electronics, the DMM6500 supports multi-channel scans with up to 10 channels, facilitating automated measurements and system profiling. Whether you want to analyze complex waveforms or profile the performance of battery-powered devices, the DMM6500 is your reliable partner for precise, meaningful measurements.

Other features:

Large internal memory for up to 7 million readings.
Multilingual modes including SCPI, TSP scripting, and emulation modes for Keithley 2000 and Keysight 34401A.
Backed by a comprehensive three-year warranty that provides reliability and peace of mind.

Lieferumfang

DMM6500 Digital Multimeter
Power cord
One pair, standard test lead set, 1000 V Cat I
USB cable, Type A to Type B, 1 m
Calibration certificate
