Keysight EDU34450A | Digital multimeter, 5½ digits, dual display, 110 readings / s, Smart Bench Essential
Manufacturer number: EDU34450A
Keysight EDU34450A | Digital multimeter, 5½ digits, dual display, 110 readings / s, particularly robust, Smart Bench system multimeter ideal for industry and training.
Technical Data
2-/4-wire: | 2-/4 |
---|---|
Accuracy voltage measurement AC: | 0,2 % |
Accuracy voltage measurement DC: | 0,018 % |
Article number: | EDU34450A |
Capacity measuring range: | 1 nF - 10 mF |
Current measuring range AC: | 10 mA - 3 A |
Current measuring range DC: | 10 mA - 3A |
Dimensions (L x W x H) (mm): | 119 x 314 x 165 |
Diode test / continuity test: | Yes / Yes |
Display: | graphic |
Frequency measuring range: | 12 Hz - 1,19 MHz |
Interfaces: | USB, LAN |
Measurements per second: | 110 |
Model: | EDU34450A |
Number of positions: | 5.5 |
Resistance measuring range: | 100 Ω - 100 MΩ |
Special features: | Dual measurement |
Temperature measurement: | Yes |
Voltage measuring range AC: | 100 mV - 750 V |
Weight (kg): | 3.35 |
max. Measuring range DC (V): | 1000 |
min. Measuring range DC (mV): | 100 |
Description
EDU34450A | Digital multimeter, 5½ digits, dual display, 110 readings / s, Smart Bench Essential
The Keysight EDU34450A is a modern digital multimeter (DMM) with a resolution of 5½ digits and a measuring rate of up to 110 readings / s for speed-critical tests. The EDU34450A has a generous internal memory which enables extended data recording of up to 5,000 data points.
When developing the multimeter, particular attention was paid to the highest level of reliability and a particularly robust design.
The EDU34450A combines hard and soft keys. It has function keys, so-called hard keys, for easy access to the most frequently used measurement functions. In addition, the intuitive softkeys allow you to make advanced configurations if required.
The DMM has an integrated Gigabit LAN and USB. Remote connectivity allows you to connect to PathWave BenchVue DMM software for advanced data logging and export of the logged data.
The EDU34450A has a 7-inch color display with two measured value displays. With this innovation, you can display your measurement setup, device status, measured values and statistics all at once, without having to scroll through multiple screens.
The multimeter also has a secondary display that allows you to see the primary and secondary components of your input signal at the same time.
The EDU34450A also features a built-in USB memory port so you can use a USB flash drive to save your DMM setup. This feature helps you install the same setup in all DMMs in your lab.
Product features:
- Measures 11 input signals: DC voltage, DC current, true rms AC voltage, AC current, two- and four-wire resistance, frequency, continuity, diode test, temperature and capacitance
- Special 7-inch color display with double display
- Fast reading rate of up to 110 measured values / s for speed-critical measurements
- 5,000 points logging memory for recording further data and performing analyzes with graphic display
- USB and LAN for flexible PC connection
- USB flash drive support to copy / load configuration for repeated test setup
- Includes PathWave BenchVue DMM software for remote control and data logging
- CAT II, 300 V: CAT I 1000 Vdc 750 Vac rms
