Keysight EDU33212A | Function generator / arbitrary signal generator, 20 MHz, 2 channels, Smart Bench Essential

Name: EDU33212A | Function generator / arbitrary signal generator, 20 MHz, 2 channels, Smart Bench Essential
Brand: Keysight
SKU: EDU33212A
Price: 1039.0 EUR
Availability: InStock

Manufacturer number: EDU33212A

2 in stock. Ready to ship in 1 business day

€1,039.00

plus VAT. €1,236.41 VAT plus shipping costs

or choose one of the following options:

Product inquiries

Keysight EDU33212A | Function generator / arbitrary signal generator, 20 MHz, 2 channel, Smart Bench function generator for industry and training.

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Arbitrary amplitude resolution:	16-bit
Arbitrary function:	Yes
Arbitrary sampling rate:	250 MS/s
Article number:	EDU33212A
Burst:	Yes
Dimensions (L x W x H) (mm):	314 x 165 x 130
Display:	7", WVGA
Frequency range pulse:	1 µHz - 10 MHz
Frequency range rectangle:	1 µHz - 20 MHz
Frequency range triangle/ramp:	1 µHz - 200 kHz
Interfaces:	USB, LAN
Model:	EDU33212A
Modulation types:	AM, FM, PM, FSK, BPSK, PWM
Number of channels:	2
Special features:	Remote control via PC with Keysight's PathWave BenchVue software
Sweep:	Yes
Warranty (years):	3
Waveforms:	Sinus, Rechteck, Rampe, Puls, Dreieck, Gaußsches Rauschen, PRBS, DC, EKG
Weight (kg):	3.1
max. Frequency sine (MHz):	20
min. Frequency sine (µHz):	1

Description

EDU33212A | Function generator / arbitrary signal generator, 20 MHz, 2 channels, Smart Bench Essential

The Keysight function / arbitrary signal generators of the EDU33210 series offer you numerous additional functions in addition to standard signals and functions such as modulation, sweep and burst. The 20 MHz generators have 17 built-in arbitrary waveforms. Generate common waveforms - sine, square, ramp, triangle, pulse, PRBS, DC and Gaussian noise, as well as special waveforms like heart waveform, exponential decay, exponential rise, Gaussian pulse, Haversine, Lorentz, D-Lorentz, negative ramp and Sinc. The six built-in modulations are AM, FM, phase modulation (PM), frequency shift keying (FSK), binary phase shift keying (BPSK) and pulse width modulation (PWM).

The 7 inch WVGA color display (Wide Video Graphics Array) offers you both the waveform setting and other parameters in one view and, in combination with the well thought-out user interface on the front of the device, enables simple and intuitive operation.

The 20 MHz function / arbitrary waveform generators are equipped with USB and LAN connectivity as standard, which facilitates remote access and control. They support operation via standard programmable instrument commands (SCPI), IVI drivers (Interchangeable Virtual Instruments), web browsers or Keysight's Pathwave BenchVue software.

The EDU33210 series also has an integrated USB memory port, which you can use to save setup parameters with a USB flash drive. This feature maximizes efficiency when you need to restore the same setup across all function / arbitrary waveform generators in your laboratory. You can also use it to quickly load the arbitrary signal into the function generator.

Product features:

Use the 7-inch WVGA color display to set parameters, view and edit signals at the same time.
With six built-in modulation types and 17 common waveforms, you can simulate typical applications for tests.
Create 16-bit arbitrary waveforms with up to 8 M samples of memory per channel.
Use the USB / LAN IO interface for remote access.
Remote control via PC with Keysight's PathWave BenchVue software.
