EA Elektro-Automatik PSB10060-10004U | DC power supply, bidirectional, 30 kW, 60 V, 1000 A

Name: PSB10060-10004U | DC power supply, bidirectional, 30 kW, 60 V, 1000 A
Brand: EA Elektro-Automatik
SKU: PSB10060-10004U
Availability: OutOfStock

Manufacturer number: PSB10060-10004U

Delivery time upon request

On Request

or choose one of the following options:

Product inquiries Request education-price

EA electro-automatic PSB10060-10004U | Programmable DC high-performance power supply and electronic load with power regeneration in one device, 0 - 60 V / 1,000 A / 30 kW in 19-inch format with only 4 U.

Output voltage: 0 ... 60 V DC
Output Current: 1,000A
Power: 30kW
Flexible, power-controlled DC<->AC stage
Protection functions (OVP, OCP, OPP, OTP)
Intuitive TFT touch panel with display for all values, status displays and messages
Remote sensing input with automatic detection
Galvanically isolated analog interface
Integrated function generator
Battery test, MPP tracking simulation
PV simulation according to DIN EN 50530
No power reduction under load
Energy recovery with high efficiency
Optional digital interface modules
SCPI command language, ModBus RTU
LabView support through VI package
Mains connection 360..528 VAC
19 inch, 4U housing
Guarantee: 2 years

Independent Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

AC input:	380 V - 480 V
Additional functions:	Funktionsgenerator mit Arbiträrfunktion, Netzrückspeisung, Simulation von Solarzellen und Brennstoffzellen, Maximum Power Point Tracking (MPPT), Regelmodus CV, CC, CP, CR, TFT - Touchscreen
Article number:	30000800
Autorange:	Yes
Bidirectional:	Yes
DC output reversible:	DC bidirectional
Dimensions (L x W x H) (mm):	670 x 482,6 x 177,80
Interfaces:	USB, Ethernet, Analog
Model:	PSB10060-10004U
Output power (kW):	30
Power factor:	> 0,99
Protective devices:	OVP, OCP, OPP, OTP, PF, SF
Warranty (years):	2
Weight (kg):	50
max. Power (A):	1000
max. Voltage (V):	60

Description

PSB10060-10004U | DC power supply, bidirectional, 30 kW, 60 V, 1000 A

PSB10000 series bidirectional regenerative laboratory power supplies (DC power supply and an electronic load with regenerative power supply in one device). With the PSB10000 series, EA Elektro-Automatik has developed a power supply that combines a DC power supply and an electronic load with regenerative feedback in one device. As a result, both the energy costs and the acquisition costs for the conventional or regenerative loads that would otherwise be required can be reduced.

As a power supply, the bidirectional power supply can charge and discharge batteries, fuel cells and other energy storage devices. As a result, the device has built-in features such as a battery test mode, an arbitrary generator, and an automotive start-up curve. In addition, with the PSB 10000, the energy generated in test processes can be recorded with low losses and in an environmentally friendly manner and fed back into the three-phase network.
