B&K Precision 1737 | DC Power Supply Unit, Dual Range 30 V / 3 A or 60 V / 2 A, Series 1737 & 1747

Name: 1737 | DC Power Supply Unit, Dual Range 30 V / 3 A or 60 V / 2 A, Series 1737 & 1747
Brand: B&K Precision
SKU: BK1737
Price: 665.0 EUR
Availability: InStock

Manufacturer number: BK1737

Delivery time upon request

€665.00

plus VAT. €791.35 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

B&K Precision 1737 | DC power supply unit, dual range 30 V / 3 A or 60 V / 2 A, series 1737 & 1747.

Technical Data

AC input:	120 V / 220 V ±10 %, 50 Hz / 60 Hz
Additional functions:	CV, CC zwei Spannungsbereiche, Fernsteuerung
Article number:	BK1737
Autorange:	No
Bidirectional:	No
DC output reversible:	DC Source
Dimensions (L x W x H) (mm):	318 x 140 x 158
Interfaces:	RS-232
Model:	BK1737
Number of outputs:	1
Protective devices:	OLP, Verpolungsschutz
Weight (kg):	4.8
max. Power (A):	3
max. Voltage (V):	60

Documents & Downloads

Datasheet

pdf | 2.56 MB

Description

1737 | DC Power Supply Unit, Dual Range 30 V / 3 A or 60 V / 2 A, Series 1737 & 1747

The 1737 and 1747 power supplies from B&K Precision are versatile DC power supplies with a dual voltage range. These power supplies allow either a higher voltage at a lower current or a higher current at a lower voltage. Thanks to excellent voltage regulation and low noise, they are suitable for numerous applications.

The devices offer constant voltage (CV) and constant current (CC) regulation and are equipped with two easy-to-read 4-digit LED displays that show voltage and current in real time. They can be operated both via the front panel and remotely via the RS-232 interface.

These power supply units are ideal for use in service workshops, engineering laboratories, production, training laboratories and for home use. Thanks to their compact design, they take up little space and are easy to transport.

The Variant 1737 presented here offers a voltage range of 0 to 60 V and enables either up to 3 A at up to 30 V or up to 2 A at up to 60 V in two operating ranges. In comparison, the Variant 1747 offers a higher maximum current of up to 10 A (at up to 35 V) or 5 A (at up to 60 V).

Product features:

Voltage output: 0-60 V
Current output:
- 0-3 A (at 0-30 V)
- 0-2 A (at 0-60 V)
Voltage regulation: ±0.01% + 3 mV
Current regulation: ±0.2% + 3 mA
Ripple & Noise (20 Hz - 20 MHz):
- Voltage: 1 mVrms
- Current: = 3 mArms
Recovery time: = 100 µs
Display resolution:
- Voltage: 10 mV
- Current: 1 mA
Display accuracy: ±0.5% + 9 digits
Power supply: 120/220 VAC ±10%, 50/60 Hz
Power consumption: = 180 VA
Protection mechanisms: Reverse polarity protection, current limiting
Weight: 4.8 kg
Dimensions (W x H x D): 140 x 158 x 318 mm
Warranty: 2 years
