Rohde&Schwarz NGP804 | DC power supply, 4 channel, 800 W, 4 x 32 V / 20 A, resolution 1 mV / 0.5 mA, NGP800 series (5601.4007.02)

Name: NGP804 | DC power supply, 4 channel, 800 W, 4 x 32 V / 20 A, resolution 1 mV / 0.5 mA, NGP800 series (5601.4007.02)
Brand: Rohde&Schwarz
SKU: 5601.4007.02
Price: 5330.0 CHF
Availability: InStock

Manufacturer number: 5601.4007.02

4 in stock. Ready to ship in 1 business day

CHF 5,330.00

plus VAT. CHF 5,761.73 VAT plus shipping costs

or choose one of the following options:

Product inquiries

Rohde & Schwarz 5601.4007.02 | DC power supply NGP804, 4 channel, 800 W, 4 x 32 V / 20 A, resolution 1 mV / 0.5 mA, NGP800 series.

Display: TFT 5 “touch screen
Channels: 4
Output power: 800 W.
Output voltage per channel: 0… 32 V
Current per channel: 20 A.
Resolution: 1 mV / 0.5 mA
Front connections: 4 mm safety connections
Rear connectors: 8-pin connector block
Connections: USB-TMC, USB-CDC (Virtual COM), LAN
Dimensions: 362 mm × 100 mm × 451 mm
Weight: 8 kg

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

AC input:	100 V - 250 V
Additional functions:	Data logger Arbitrary function Remote sense Measurement functions
Article number:	5601.4007.02
Autorange:	No
Bidirectional:	No
DC output reversible:	DC Source
Dimensions (L x W x H) (mm):	451 x 362 x 100
Interfaces:	USB-TMC, USB-CDC (Virtual COM), LAN optional: GPIB
Model:	NGP804
Number of outputs:	4
Output power (kW):	0.8
Protective devices:	OVP, OPP, OCP, OTP
Warranty (years):	3
Weight (kg):	8
max. Power (A):	20
max. Voltage (V):	32

Description

NGP804 | DC power supply, 4 channel, 800 W, 4 x 32 V / 20 A, resolution 1 mV / 0.5 mA, NGP800 series (5601.4007.02)

The Rohde & Schwarz laboratory power supply series NGP800 consists of five models with 400 W / 800 W and 2 or 4 channels, each with 200 W per channel.

The 5 models of the NGP800 series deliver, depending on the variant, up to 32 V / 64 V voltage with a current of 20 A / 10 A per channel.

The NGP804 variant has 4 channels, each with 0 V… 32 V / 20 A and a power of 800 W.

All Rohde & Schwarz NGP800 power supplies have remote sense terminals for regulating the output voltage directly at the test device's input connections, a USB connection and a LAN interface. A user-installable GPIB interface, digital trigger I / O and an analog input are optional, making these instruments ideal for use on the test bench or in an automated test system.

Full flexibility:

5 "high-resolution touch display
FlexPower - changing V / A combinations
up to four power supplies in one instrument
Parallel and serial operation

Full functionality:

Ramp function
Exit delay
Arbitrary functions
Remote sensing
Built-in measurement functions
Data acquisition

Complete security:

Protective functions
Security limits
Safe work environment

Full connectivity:

Digital remote control
Digital trigger I / O
Analog input
