Pico TA058 | Probe, differential 10: 1, 50 MHz, ± 700V, BNC
Manufacturer number: TA058
or choose one of the following options:
Detaildescription
TA058 | Probe, differential 10: 1, 50 MHz, ± 700V, BNC
The TA058 is a CAT I rated differential oscilloscope probe that can measure up to ± 70 volts.
Specifications for the TA058 differential probe:
- Bandwidth: DC to 50 MHz (- 3 dB)
- Input impedance: 1.6 MΩ / 7 pF from each input to ground
- Attenuator: 10: 1
- Input voltage:
Max. Differential voltage: ± 70 V (DC + peak AC) or 70 V rms
Common mode input voltage: ± 700 V (DC + peak AC) or 600 V rms - Maximum input voltage: ± 700 V (DC + peak AC) or 600 V rms, CAT I
- Accuracy: ± 1%
- Rise time: <7 ns
- Output voltage:
Signal (in 5 kΩ load): ± 7V
Offset (typical): <± 2 mV
Noise (typical): 0.7 mV rms - Output impedance (typical): 50 Ω
- Supply voltage: 6 V / 90 mA DC or 9V DC / 70 mA, optional battery box (4xAA cells) or supply adapter
- Length of the connecting wires: 50 cm
- Length of the shielded BNC cable. 125 cm
- Weight: 300 g
- Dimensions: (W) 22mm X (L) 111mm X (H) 14mm
