Pendulum CNT-90XL-27G | Microwave frequency counter / analyzer, 27 GHz, graphical, incl.option CNT-OPT-19-90

Manufacturer number: CNT-90XL-27G

Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Pendulum CNT-90XL-27G
Delivery time upon request

CHF 9,657.00

plus VAT. CHF 10,439.22 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Scope Related Articles

Pendulum CNT-90XL-27G | Frequency counter and analyzer, up to 27 GHz, with integrated power measurement and pulse option, speed up to 250 kSa / s, OCXO time reference.

  • Number of channels: 3
  • Time reference: OCXO (oven-controlled crystal oscillator)
  • Measuring range: 0.002 Hz to 400 MHz (CH 1 + 2), 300 MHz to 27 GHz (CH 3)
  • Measurement resolution: 12 digits / s (frequency), 100 ps (time, single shot), 2.5 mV (voltage)
  • Measuring speed: 250,000 Sa / s
  • Internal memory for max. 750,000 readings
  • Measurement functions / statistics: power, frequency, period, time range, phase, duty cycle, pulse width, PRE, rise / fall time, voltage, peak voltage / mean, minimum, maximum, standard deviation, Allan deviation (ADEV)
  • Minimum pulse width: 1.6 ns
  • Attenuators: x1, x10
  • Trigger sources: internal, external (interface), manual
  • Interfaces: USB, GPIB
  • Power supply: 90 - 265 V, 45 - 440 Hz, optional battery operation
  • Dimensions and weight: W 210 x H 90 x D 395 mm, 2.7 kg
  • 3 year guarantee

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Datasheet
pdf | 0.47 MB
Userguide
pdf | 9.62 MB

Description

CNT-90XL-27G | Microwave frequency counter / analyzer, 27 GHz, graphical, incl.option CNT-OPT-19-90

The multifunctional frequency counter CNT-90XL from Pendulum Instruments is used on the one hand as an ultra-fast and high-resolution 400 MHz universal counter and timer. As a high-performance analyzer for the precise measurement and calibration of frequencies, powers and pulsed HF up to 30 ns, e.g. B. the pulse width or PRI / PRF (pulse repetition interval / frequency), it is also used in research and development, in radar tests or in calibration laboratories. Its speed enables up to 250,000 measurements per second. The measurement resolution for the time domain measurement is up to 100 ps. The CNT-90XL displays frequency measurements with 12 digits. The unique user-friendliness of the CNT-90XL with graphic and numerical display enables optimal control over your analyzes. The portable frequency counter with battery is available for maximum versatility.

High performance timer / counter / analyzer:
  • High resolution for efficient use in research, development and production (100 ps for time, 12 digits for frequency measurements)
  • With analysis function for modulation domains through the detection of fast frequency changes with up to 250 kSa / s
  • Zero dead time technology and the continuous time stamping of trigger events enable the correct measurement of the Allan deviation (ADEV) as well as mechanical or medical applications (e.g. nerve impulses, breathing)
  • Very high accuracy due to OCXO time reference for calibration purposes
  • Large frequency range up to 27 GHz for all CW (continuous wave) and burst RF applications
  • Clear display for optimal interpretation of your measurement results with histogram, trend line, numerical statistics, modulation domain
  • Outstanding price-performance ratio

    • With the modulation domain analyzer software TimeView 2, you can expand your measurement and statistical functions to analyze dynamic signal changes of time or frequency in real time, e.g. B. for measuring frequency stability (Allan deviation, ADEV) or for FFT to find modulation frequencies.

    Examples of use:
    • Testing and calibration of pulsed, Doppler pulse and chirp radar signals
    • Testing systems for satellite communications
    • Calibration of high-frequency measuring devices
    • RF component test, including YIG / VC oscillators (voltage-controlled oscillators)
    • Medical HF device testing

    Lieferumfang

    • Power cord
    • Operating instructions (CD)
    • Calibration certificate
