GW Instek PEL-5010C-600-700 | Electronic load, DC, 600 V / 700 A / 10 kW, PEL-5000C series
Manufacturer number: PEL-5010C-600-700
GW Instek PEL-5010C-600-700 | Electronic DC load, 10 kW, 0… 70/700 A, 0… 600 V, PEL-5000C series.
Documents & Downloads
Description
PEL-5010C-600-700 | Electronic load, DC, 600 V / 700 A / 10 kW, PEL-5000C series
The electronic high-power DC loads of the GW Instek PEL-5000C series are ideal for emulating battery systems, for quality control in R&D, in ATE systems and for production tests. Each model has two switchable current ranges and the voltage range is 150 V.
The DC loads have their own control and display panel. Settings can be made and read quickly and easily. Optional GPIB, RS232, USB or LAN interfaces integrate the Electronic Load optimally into your test environment.
Control of several loads with one MASTER and up to 7 devices in parallel SLAVE operation up to max. 192 kW.
You get the electronic loads of the GW Instek PEL-5000C series in different versions with up to 24 kW power with a maximum of 2,000 A. Maximum voltage 150V, 600V or 1,200V.
The PEL-5010C-600-700 variant presented here has a range of 0 - 600 V, 0 - 70/700 A and an output of 10 kW.
Further product features of the PEL-5000C series:
- CC / CR / CV / CP / Dynamic Modes
- 150 store / recall memory sets
- Optional GPIB / RS232 / USB or LAN interface
- SHORT Time Setting and SHORT_VH, SHORT_VL function for measuring very short voltages and currents
- External signal input for an arbitrary waveform generator to simulate the load current
- High efficiency and accuracy in OCP / OPP testing
- Programmable load ON / OFF voltage
- GO / NG meter test
- Voltmeter display "+" or "-"
