NI 782878-01 | NI PXIe-4322, Isolated Analog Output Module

Name: 782878-01 | NI PXIe-4322, Isolated Analog Output Module
Brand: NI
SKU: 782878-01
Price: 5010.0 CHF
Availability: OutOfStock

Manufacturer number: 782878-01

Delivery time upon request

CHF 5,010.00

plus VAT. CHF 5,415.81 VAT plus shipping costs

or choose one of the following options:

Product inquiries

782878-01 | NI PXIe-4322, Isolated Analog Output Module.

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Bustype:	PXI Express
Connection type front:	96-Pin, Männlich DIN
Isolation of the analogue output:	300 Veff Kanal-zu-Kanal-Isolierung
Max. Output current (mA):	20
Max. Update rate (MS/s):	0.25
Module width:	1
Number of analogue output channels:	8
Output current measuring range:	-20 mA bis 20 mA
Protectively coated:	No
Voltage range of the analogue output (V):	-16 V bis 16 V
With case:	Yes

Description

782878-01 | NI PXIe-4322, Isolated Analog Output Module

The PXIe ‑ 4322 is a channel-wise isolated analog output module with integrated signal conditioning. The module provides accurate, simultaneous dynamic voltage and current outputs. By combining signal conditioning and D / A converters in one device, the isolated analog output module PXIe ‑ 4322 offers smaller dimensions and higher measurement performance. In power mode, the module works in all four quadrants, so power can be drawn and delivered. Thanks to insulation and outputs for higher voltages and currents, the module is particularly suitable for applications in the automotive sector.

Product features:

Bus type: PXIe
Maximum update rate: 8
Voltage measuring range analog output: 250 kS / s
Resolution analog output: -16 V to 16 V
Output current measuring range: 16 bit
Heading 3: -20 mA to 20 mA

Accessoires (4 products )

NI 960680-101

Standard Service Program (SSP) for PXIe-4322 with Traceable Calibration, 3 Years (782878-01-SC3)

Delivery time upon request

CHF 1,242.53

NI 960455-03

ANSI Compliant Calibration Certificate for PXIe-4322 (782878-01-ANSI)

Delivery time upon request

CHF 560.00

NI 960455-01

Traceable Calibration Certificate for PXIe-4322 (782878-01-CAL)

Delivery time upon request

CHF 325.00

NI 960455-04

ISO 17025 Calibration Certificate for PXIe-4322 (782878-01-ISO)

Delivery time upon request

CHF 720.00
