GW Instek MSO-2102EA | Oscilloscope, 2 + 16 channels with 2 channels AFG 100 MHz, 1 GSa / s, 120,000 wfm / s, 10 MPts, USB, LAN

Manufacturer number: MSO-2102EA

GW Instek MSO-2102EA | Mixed signal oscilloscope, 2-channel with 16-channel logic analyzer, 100 MHz, sampling rate 1 GSa / s per channel, refresh rate 120,000 wfm / s, memory depth 10 Mpts per channel, with built-in 25 MHz function generator.

  • Channels: 2 analog + 16 digital (1GSa / s with 200 MHz bandwidth)
  • Analog bandwidth: 100 MHz
  • Sampling rate: 1 GSa / s per channel in real time
  • Memory depth: 10 Mpts
  • Signal acquisition rate: 120,000 wfm / s
  • VPO (Visual Persistence Oscilloscope) Waveform Display Technology for more signal information similar like with analog oscilloscopes
  • FFT frequency analysis down to 1 Mpts depth
  • High pass and low pass filter functions
  • Autoset function
  • 38 Automatic measurement functions
  • Segmented memory function (29,000 segments)
  • Frequency counter
  • BUS trigger and decoding: I²C / SPI / UART / CAN / LIN
  • Frequency Response Analyzer FRA (Bode Plot) application (from firmware V1.34 or later)
  • Long-term data tracking: up to 100 hours
  • Arbitrary 2-channel 25MHz function generator (sample rate 200 Msa / s, 14 bits, 10 mVpp to 2.5 Vpp at 50 Ω)
  • Display: 8 inches (20.32 cm diagonal) WVGA TFT LCD display / 800x480px
  • Multi-language menu
  • Connections: USB 2.0, LAN, Go / No-Go BNC, Kensington Style Lock.
  • Network storage function
  • Software and drivers: USB driver, PC software (OpenWave software).
  • Weight: 3 kg
  • Dimensions: W 384 mm x H 208 mm x D 127.3 mm

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Description

MSO-2102EA | Oscilloscope, 2 + 16 channels with 2 channels AFG 100 MHz, 1 GSa / s, 120,000 wfm / s, 10 MPts, USB, LAN

The mixed signal oscilloscopes of the MSO-2XXXEA series are significantly more than just a further development of the successful GW Instek GDS-2000 series. The high functionality as well as the high-performance software and hardware should be preserved and further improved. The oscilloscopes of the MSO-2000 series continue to have the excellent refresh rate of 120,000 wfm / s and the high memory depth of 10Mpts per channel. However, the components of the measuring devices have been significantly improved and increased - and all of this at a very reasonable price.

The 2-channel, 100 MHz oscilloscope MSO-2102EA has the excellent memory depth of 10 Mpts per channel and already has a logic analyzer and an arbitrary function generator. The logic analyzer has 16 channels. Measure and test more and longer digital signals. The analyzer has a serial bus (I²C, SPI, UART, CAN, LIN), a parallel bus and the trigger functions Edge, Pattern and Pulse Width.

The devices of the MSO 2000EA series are also already equipped with an arbitrary function generator (wave generator). This 2-channel function generator has a bandwidth of 25 MHz, a vertical resolution of 14 bits and a sample rate of 200 Msa / s. The function generator allows you 5 standard waveforms (sine, square, pulse, tilting (ramp), DC and noise), 7 user-defined waveforms (Sinc, Gauss, Lorentz, exponential rise and fall, Haversine, Cardiac), AM / FM / FSK Modulations and sweep functions.

The GW Instek MSO2102EA is ideally suited for educational and training institutions as well as industrial users, for example from the automotive or information and communication technology sectors.

Lieferumfang

  • 1 passive probe per channel, 16-channel digital probe (Logic Analyzer Probe) GTL-16E, power cord, calibration certificate, CD-ROM (Quick Start Guide, User Manual, Programming Manual), 2m BNC to BNC cable GTL-110
  • 3 year guarantee
