Gossen Metrawatt M681Y | WR100-12R Microohmmeter up to 100 A for checking contact, connection and winding resistance on inductors up to 1,500 Henry

Name: M681Y | WR100-12R Microohmmeter up to 100 A for checking contact, connection and winding resistance on inductors up to 1,500 Henry
Brand: Gossen Metrawatt
SKU: M681Y
Price: 47355.0 CHF
Availability: OutOfStock

Manufacturer number: M681Y

Delivery time upon request

CHF 47,355.00

plus VAT. CHF 51,190.76 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries

Gossen Metrawatt M681Y | WR100-12R MicroOhmmeter up to 100 A.

High-performance DC supply (100 A/ 50 V)
Demagnetization function for transformers and automatic discharge
Extremely large measuring range from 0.00μΩ to 100 kΩ, charging current adjustable
2 measuring channels
3 temperature channels (with automatic resistance correction)
Optical and acoustic display of the discharge status
Data storage of up to 10,000 measurements
Data exchange with USB stick
Color touchscreen with backlight
"Warning output" for transformer under test
Emergency stop button, power off and discharge begins

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Description

M681Y | WR100-12R Microohmmeter up to 100 A for checking contact, connection and winding resistance on inductors up to 1,500 Henry

2/3-channel microohmmeter in a 19" rack up to 100 A 50 V for checking contact resistance, connection and winding on inductances up to 1500 Henry in the high and medium voltage range as well as continuity and length measurements on cables and cable shields.

The WR100-12R was developed for use in the high and medium voltage range. Thanks to the powerful 100 A / 50 A mains part and the sophisticated automatic discharge, the charging and discharging times of inductive test objects are significantly reduced. The devices also have a demagnetization function that ensures a secure connection to the mains.

The 3-channel version enables measurements to be carried out faster than usual. By connecting the entire primary winding in series, all inductances are charged simultaneously. The resistance is measured separately for each winding. A three-phase unit can therefore be completely measured in 2 measuring steps. .

Lieferumfang

Power and potential cable set 10m
Operating instructions
Jumper cable 10m
Software for downloading data
