Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device

Manufacturer number: M555A

Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device
Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device
Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device
Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device
Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device
Gossen Metrawatt METRISO PRIME10 insulation, low-resistance & voltage measuring device
Delivery time upon request

CHF 5,245.00

plus VAT. CHF 5,669.84 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries Request education-price
Highlights Documents / Downloads Description Scope Related Articles

Gossen Metrawatt M555A | METRISO PRIME10 High-precision insulation, low-resistance and voltage measuring device up to 40 TΩ at 10 kV test voltage.

  • Insulation measurement according to EN 61557-2 / VDE 0413 part 2
  • Test voltages in fixed steps: 50 V, 100 V, 250 V, 500 V, 1000 V, 2500 V, 5000 V, 10000 V
  • Measurement with gradually increasing voltage
  • Measuring range up to 40 TΩ according to IEC 61557-2
  • Measurement of polarization index and absorption ratio
  • Measurement with shielded measuring line
  • Protection against live objects
  • Variable setting of limit values
  • Digital filter to stabilize the measured values
  • Creation of R / I or R / U diagrams
  • Storage of test results
  • Low resistance measurement according to EN 61557-4 / VDE 0413 part 4
  • Continuity test of protective conductors and equipotential bonding connections with test current> 200 mA
  • Permanent display of the measured insulation resistance or leakage current
  • Automatic discharge of the device under test at the end of the insulation test
  • Acoustic signal in 5 second intervals, for fast
  • Creation of a time resistance characteristic
  • Adjustable measuring times up to 99'59 ''
  • Test times T1, T2 and T3 for measuring one or two absorption coefficients in the range from 1 ... 600 s
  • Polarization index (PI), absorption coefficients Ab1, Ab2, dielectric absorption ratio (DAR)
  • Display of the current test voltage during the measurement
  • Test currents: 1.2 mA, 3 mA and 5 mA
  • Insulation test can be carried out using the 2- or 3-wire method
  • Measurement can be carried out with measuring lines up to 55 m
  • Automatic measurement of multi-core cables with the optional AutoISO-5000 test adapter (max. Voltage 5 kV)
  • Measuring the capacitance during the insulation test RISO
  • Temperature measurement with probe as an accessory
  • Dielectric discharge (DD)
  • Fault location through pulse burning mode
  • Adjustable limit values for measured resistances of RISO and RCONT
  • Measurement of leakage currents during the insulation test DC and AC voltage measurement from 0 ... 750 V
  • Graphic display of the insulation resistance on the display during the measurement
  • New storage structure by storing: measuring points, systems and customer data
  • Using a mini bluetooth keyboard (optional)
  • 5.6 inch LCD display with backlight
  • Keyboard lighting
  • Supply via mains voltage or lithium-ion battery
  • Internal quick charger
  • Dimensions 390 mm x 310 mm x 180 mm
  • Weight about 7 kg
  • Degree of protection according to EN 60529 IP40 (IP67 for closed housing)

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Datasheet
pdf | 0.48 MB

Description

METRISO PRIME10 insulation, low-resistance & voltage measuring device

The METRISO PRIME 10 insulation tester was developed to check insulation damage and to protect against electric shock in supply networks.

It measures resistances up to 40 TeraOhm at 10 kV test voltage according to EN 61557-2. Absolutely precise measurement results are achieved even with high-frequency interference. Flaws can be localized quickly and easily using the new "burning function". Insulation measurements such as PI, DAR, DD, step test (SV), capacitance measurement, temperature measurement and the measurement of the continuity of the protective conductor are possible without any problems. These measurement processes can be immediately shown graphically on the display.

Lieferumfang

  • 1 METRISO PRIME 10
  • 1 test lead set consisting of:
    - 11 kV line, 3 m, (CAT IV 1000 V), with banana sockets, red
    - 11 kV cable, 3 m, shielded, (CAT IV 1000 V), with banana sockets, black
    - "E" line 10 kV, 3 m, (CAT IV 1000 V), with banana sockets, blue
  • 3 alligator clips 11 kV, 32 A (CAT IV 1000 V), black, red and blue
  • 2 measuring tips 11 kV, 32 A with banana socket, red and black
  • 1 temperature probe (Z555J)
  • 1 USB cable
  • 1 230 V mains cable
  • 1 accessory bag
  • 1 instruction manual
  • 1 calibration certificate
  • 1 handling document for lithium-ion batteries

Alternate products (4 products )

Alternate products (4 products )

Gossen Metrawatt M551N
Gossen Metrawatt M551N
METRISO INTRO-SET with bag + test tip insulation measuring device 1000V, 10 k to 10 GOhm
Ready to ship in 5 to 10 business days
CHF 1,234.00
Gossen Metrawatt M550P
Gossen Metrawatt M550P
METRISO TECH insulation measuring device 1000V, 10 k to 200 GOhm
1 in stock. Ready to ship in 1 business day
CHF 1,245.00
Chauvin Arnoux P01138901
Chauvin Arnoux P01138901
CA6541 megohmmeter, 1000V, 2 kOhm to 4 TOhm
Delivery time upon request
CHF 1,593.00
Chauvin Arnoux P01139716
Chauvin Arnoux P01139716
CA 6555 insulation meter 15kV
