Gossen Metrawatt M101A | Multimeter, analogue Metrahit 2A 500 V CAT II, 15 A

Name: M101A | Multimeter, analogue Metrahit 2A 500 V CAT II, 15 A
Brand: Gossen Metrawatt
SKU: M101A
Price: 473.0 CHF
Availability: OutOfStock

Manufacturer number: M101A

Ready to ship in 5 to 10 business days

CHF 473.00

plus VAT. CHF 511.31 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries

Gossen Metrawatt M101A | Compact and robust analog multimeter METRA HIT 2A.

Analog multimeter for electrical applications
Voltage measurement 0 .. 0.15 / 0 .. 0.5 V =, 0 .. 1.5 / 5/15/50/150/500 V = / ~; 0 .. 1000 V =
Input resistance 20 kOhm / V =; 4 kOhm / V ~
Current measurement 0 .. 50 mA =; 0 .. 1.5 / 15/150 mA / 1.5 / 15 A = / ~
Resistance measurement: 1 ohm .. 1 MOhm (4 ranges)
Level: -15 .. +56 dB (6 ranges)
Accuracy: class 2.5
Dimensions: 92 x 126 x 45 mm
Weight: approx. 0.25 kg without battery
Battery: 1.5 V IEC LR 6 (mignon, AA)

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Analogue segment display:	Yes
Article number:	M101A
Backlight:	No
Basic precision:	Klasse 2,5
Capacity measuring range:	2 µF - 200000 µF
Current measuring range AC/DC:	0.50mA - 5000mA / 50µA - 5000mA
Data memory / logger:	No / No
Dimensions (L x W x H) (mm):	126 x 92 x 45
Diode test / continuity test:	No / No
Display Hold / Auto-Hold:	No / No
Frequency measuring range:	No
Interfaces:	None
Min. / Max. Recording:	No / No
Model:	M101A
Resistance measuring range:	1 Ω - 1 MΩ
Temperature measurement ( PT100 / Type K / Type J):	No
True effective measurement TRMS:	No
Voltage measuring range AC/DC:	1,5 V - 500 V / 0,15 V - 500 V
Warranty (years):	3
Weight (kg):	0.3

Description

M101A | Multimeter, analogue Metrahit 2A 500 V CAT II, 15 A

Due to the large number of measuring ranges, this multimeter can be used universally, e.g. B. in electronics, digital technology and in numerous areas of general electrical engineering. The connecting sockets and the connecting plugs of the measuring lines available as accessories are protected against accidental contact. All measuring ranges are selected with a rotary switch.
The robust plastic housing and the spring-loaded bearing stones of the moving coil measuring mechanism protect the devices from damage due to mechanical stress. The optional rubber protective cover and the optional ever-ready case offer special protection during rough operation.

Accessoires (3 products)

Gossen Metrawatt
GTY3172083P01

F809 Ever-ready case

Ready to ship in 5 to 10 business days

CHF 60.00

Gossen Metrawatt
Z115A

Hitbag belt pouch for Metrahit and Metraport

Ready to ship in 5 to 10 business days

CHF 87.00

Gossen Metrawatt
GTZ3301000R0003

F829 Carrying case suitable for MetraHit and MetraMax multimeters

1 in stock. Ready to ship in 1 business day

CHF 105.00

Alternate products (5 products)

Chauvin Arnoux
P01196523F

CA5005 multimeter, analog set - current clamp MN89, case

Delivery time upon request

CHF 546.00

Gossen Metrawatt
M102A

Metramax 2 multimeter, analog

Ready to ship in 5 to 10 business days

CHF 279.00

Chauvin Arnoux
P01196522E

CA5003 multimeter, analog IP 53

Ready to ship in 5 to 10 business days

CHF 412.00

Chauvin Arnoux
P01196521E

CA5001 analog multimeter

Delivery time upon request

CHF 308.00

Gossen Metrawatt
M242A

Metrahit PRO multimeter, hand 4 ½ digits, 12,000 digits, DAkks

Ready to ship in 5 to 10 business days

CHF 517.00

Recommendations (2 products)

Gossen Metrawatt
M611D

Duspol analog 1000 voltage tester

Ready to ship in 5 to 10 business days

CHF 65.52

Gossen Metrawatt
GTY3620034P0002

KS 17-2 test lead set

1 in stock. Ready to ship in 1 business day

CHF 46.00

About the Manufacturer

Gossen Metrawatt

Safety through competence. With over 100 years of experience, Gossen Metrawatt offers you unique products for measurement and testing technology as well as industrial metrology. The products stand for quality, reliability, safety and progressiveness, but also for dynamic and ergonomic design, high ease of use and unique innovative spirit.
