Gossen Metrawatt METRAHIT ISO | Multimeter, TRMS, 3 ¾, IP54, integr. Insulation measurement (M246B)

Name: METRAHIT ISO | Multimeter, TRMS, 3 ¾, IP54, integr. Insulation measurement (M246B)
Brand: Gossen Metrawatt
SKU: M246B
Price: 1059.0 CHF
Availability: InStock

Manufacturer number: M246B

2 in stock. Ready to ship in 1 business day

CHF 1,059.00

plus VAT. CHF 1,144.78 VAT plus shipping costs

or choose one of the following options:

Product inquiries

Gossen Metrawatt M246B | 4 stell-digit TRMS multimeter and insulation meter METRAHit ISO. Ideal for electrical service.

Insulation resistance measurement with external voltage detection
Test voltages: 50 V, 100 V, 250 V, 500 V, 1000 V
Multi-function multimeter (V, Ohm, F, Hz)
RMS value measurement TRMS AC / AC + DC for current / voltage up to 10 kHz
Low pass filter can be activated, 1 kHz / -3 dB in the V AC range
Direct current measurement 100 nA ... 10 A
Current measurement via clip-on current sensor clip
the transmission factor of 1 mV: 1 mA to 1 mV: 1 A is adjustable and is taken into account in the display
Precision temperature indicator ° C, ° F
for Pt100 / Pt1000 sensors and thermocouple type K
Diode measurement (IK = 1 mA, U flow up to 5.1 V) and continuity test
3-digit display, 3100 digits, lighting can be activated
Acoustic signaling for: continuity test, dangerous contact voltages and exceeding overload limits
Storage of min / max values
Measurement data storage and internal clock, power supply adapter socket
Housing in IP54, dust and splash-proof, rubber protective cover
Bidirectional infrared interface for data exchange with PC
Windows software as an accessory for processing and graphically displaying measured values via the RS232 interface
DAkkS (DKD) calibration certificate included
Warranty 3 years

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Analogue segment display:	Yes
Article number:	M246B
Backlight:	Yes
Basic precision:	0,2 %
Capacity measuring range:	30 nF - 300 µF
Current measuring range AC/DC:	300µA - 10A / 300µA - 10A
Data memory / logger:	Yes / Yes
Dimensions (L x W x H) (mm):	200 x 87 x 45
Diode test / continuity test:	Yes / Yes
Display Hold / Auto-Hold:	Yes / Yes
Display resolution:	30000
Electrical safety:	CAT II 1000 V, CAT III 600 V
Frequency measuring range:	300 Hz - 300 kHz
Interfaces:	None
Min. / Max. Recording:	Yes / Yes
Model:	Metrahit ISO
Number of positions:	4.75
Resistance measuring range:	300 Ω - 30 MΩ
Special features:	including DakkS calibration certificate
Temperature measurement ( PT100 / Type K / Type J):	Pt 100 / Pt 1000 / Type K
True effective measurement TRMS:	Yes
Voltage measuring range AC/DC:	300 mV - 1000 V / 300 mV - 1000 V
Warranty (years):	3
Weight (kg):	0.35

Documents & Downloads

Datasheet

pdf | 0.72 MB

Description

METRAHIT ISO | Multimeter, TRMS, 3 ¾, IP54, integr. Insulation measurement (M246B)

The METRAHIT ISO multimeter is a portable, robust and field-compatible measuring device. It is suitable for servicing household appliances, machines (e.g. forklift trucks) and systems (e.g. photovoltaics). The device has an internal mains-independent power supply.
