Elettrotest TPS/T/D40K | Power supply, AC, 1 / 3 phase 300 V / 100 A / 30 kVA / 10 - 80 Hz Isolated

Name: TPS/T/D40K | Power supply, AC, 1 / 3 phase 300 V / 100 A / 30 kVA / 10 - 80 Hz Isolated
Brand: Elettrotest
SKU: TPS/T/D40K
Price: 40662.0 CHF
Availability: OutOfStock

Manufacturer number: TPS/T/D40K

Delivery time upon request

CHF 40,662.00

plus VAT. CHF 43,955.62 VAT plus shipping costs

or choose one of the following options:

Product inquiries

Elettrotest TPS/T/D40K | Isolated power supply, AC, 1/3 phase, 300 V, 100 A, 30 kVA, frequency 10-80 Hz, remote control.

Versatile Output Phases: Offers the flexibility of a single or three-phase output to meet the needs of different applications.
Precise Output Control: Allows precise adjustment of the frequency, amplitude and phase of the output voltage for optimal performance and adaptability.
Stable Output Voltage: Guarantees a stable sinusoidal voltage with a distortion of less than 0.3%, regardless of the load or momentary short circuits.
User-Friendly Control: Features an intuitive 7-inch touchscreen display and remote interfaces for easy control and monitoring of output parameters.

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

AC input:	400 V ±10 % 3P
AC output:	1P / 3P
Article number:	99116413
DC output reversible:	AC Source
Dimensions (L x W x H) (mm):	625 x 940 x 1600
Frequency range:	10 Hz - 80 Hz
Grid simulation:	No
Interfaces:	RS-232, RS-485
Mains feedback:	No
Model:	TPS/T/D40K
Output power (kW):	30
PLD Testfunction:	No
Protective devices:	OVP, UVP, OTP, INV
Weight (kg):	600
max. Power (A):	33.3
max. Voltage (V):	300

Description

TPS/T/D40K | Power supply, AC, 1 / 3 phase 300 V / 100 A / 30 kVA / 10 - 80 Hz Isolated

The TPS/T/D series offers a reliable solution for applications requiring precise output voltages. With low distortion of less than 0.3% regardless of load type and a stable output voltage within 0.1% for linear loads and full load, this series ensures consistent performance.

The generators are versatile and can drive loads from purely capacitive to purely inductive. They offer continuous adjustability of the output voltage from zero to the maximum scale and can provide the nominal power at different power levels, allowing adaptation to different requirements.

Frequency control allows the output frequency to be set from 10 to 80 Hz at maximum voltage. Remote control commands allow the frequency to be adjusted up to 320 Hz, albeit at a reduced power. The frequency stability is 0.01% compared to the set frequency.

The user interface is simple and user-friendly designed, with an LCD touch screen for control. It provides clear information on the status of the output voltage and frequency with an accuracy of 0.3%. Additional functions such as wire loss compensation and automatic testing improve efficiency and functionality.

Built-in safety mechanisms protect against overcurrent and excessive wire loss, ensuring the longevity of the equipment.

The TPS/T/D series offers a reliable, precise and flexible solution for a wide range of applications requiring a controlled voltage supply.

Alternate products (5 products )

Elettrotest TPS/T/D10K

Power supply, AC, 1 / 3 phase 300 V / 24.8 A / 7.5 kVA / 10 - 80 Hz Isolated

Delivery time upon request

CHF 21,378.00

Elettrotest TPS/T/D20K

Power supply, AC, 1 / 3 phase 300 V / 50 A / 15 kVA / 10 - 80 Hz Isolated

Delivery time upon request

CHF 28,923.00

Elettrotest TPS/T/D40K

Power supply, AC, 1 / 3 phase 300 V / 100 A / 30 kVA / 10 - 80 Hz Isolated

Delivery time upon request

CHF 40,662.00

Elettrotest TPS/T/D60K

Power supply, AC, 1 / 3 phase 300 V / 240 A / 50 kVA / 10 - 80 Hz Isolated

Delivery time upon request

CHF 57,208.00

Elettrotest TPS/T/D90K

Power supply, AC, 3 phase 300 V / 107 A / 90 kVA / 10 - 80 Hz Isolated

Delivery time upon request

CHF 62,037.00

About the Manufacturer

Elettrotest

Elettrotest is a world leader in design and manufacturing of programmable voltage generators, electronic devices and controls for heating, ventilation, air conditioning and refrigeration.

The Italian company manufactures high quality electronic measurement equipment. Customized products are manufactured specifically to meet the needs and requirements of customers.
