Elettrotest CPS / M / 1000 | Power supply unit, AC, 1-phase 300V / 3.3A, 1000VA. not isolated

Name: CPS / M / 1000 | Power supply unit, AC, 1-phase 300V / 3.3A, 1000VA. not isolated
Brand: Elettrotest
SKU: CPS/M/1000
Price: 2642.0 CHF
Availability: OutOfStock

Manufacturer number: CPS/M/1000

Delivery time upon request

CHF 2,642.00

plus VAT. CHF 2,856.00 VAT plus shipping costs

or choose one of the following options:

Product inquiries

Elettrotest CPS / M / 1000 | Power supply unit, AC, 1-phase 300V / 3.3A, 1000VA. not isolated.

Inrush current: 1000VA / 2000VA
Output: single phase
Characteristic: Not isolated

TENSION:

Range: 300V
Accuracy: <0.5%
Distortion: <0.3%
Output voltage stability: <0.1%
Recovery time of the waveform: <10ms
Maximum compensated drop: 5% fs
Wire fall recovery time: <200 ms
Output voltage resolution: 0.025% fs

1 PH:

RMS continuous: (2) 300 V 3.3 A
Inrush current (3 seconds) (2) 300 V 6.7 A.

FREQUENCY:

Output frequency range: DC (1), 10Hz - 80Hz
Synchronization range: 45Hz - 65Hz
Frequency resolution: 0.02Hz
Frequency accuracy: 100ppm

CARE:

Input voltage: 230Vac ± 10% 1Ph
Input frequency: 47Hz-63Hz

OTHERS:

Size: (H: W: D) 4U: 450: 540 (3)
Weight: 25 kg
Protection: OVP, UVP; OTP
Operating temperature range: 0-35 ° C
RS232
RS485 (optional)
LAN (optional)

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

AC input:	230 V ±10 % 1P
AC output:	1P
Article number:	99112103
DC output reversible:	AC Source
Dimensions (L x W x H) (mm):	540 x 450 x 177,8
Frequency range:	10 Hz - 80 Hz
Grid simulation:	No
Interfaces:	RS-232 Optional: LAN, RS-485
Mains feedback:	No
Model:	CPS/M/1000
Output power (kW):	1
PLD Testfunction:	No
Protective devices:	OVP, UVP, OTP
Weight (kg):	25
max. Power (A):	3.3
max. Voltage (V):	300

Description

CPS / M / 1000 | Power supply unit, AC, 1-phase 300V / 3.3A, 1000VA. not isolated

The CPS / M / 1000 is a single-phase AC / DC source that offers a sinusoidal and continuous waveform with high properties in terms of purity, stability and accuracy. The CPS / M / 1000 is voltage and frequency programmable and, due to its properties, suitable for the power supply of single-phase devices.

News and Knowledge

Modern applications for power supplies.

Power supply units are as diverse as their areas of application. What do you personally use your power supply unit for? ...

17/03/2021

Reading time 5 Min.

257

About the Manufacturer

Elettrotest

Elettrotest is a world leader in design and manufacturing of programmable voltage generators, electronic devices and controls for heating, ventilation, air conditioning and refrigeration.

The Italian company manufactures high quality electronic measurement equipment. Customized products are manufactured specifically to meet the needs and requirements of customers.
