Teledyne FLIR E86 | Thermal imaging camera 464x348px 14°/24° DUAL FOV, 30Hz, up to +1500°C, 50mK, MSX (78518-1301)

Name: E86 | Thermal imaging camera 464x348px 14°/24° DUAL FOV, 30Hz, up to +1500°C, 50mK, MSX (78518-1301)
Brand: Teledyne FLIR
SKU: 78518-1301
Price: 13856.0 CHF
Availability: OutOfStock

Manufacturer number: 78518-1301

Delivery time upon request

CHF 13,856.00

plus VAT. CHF 14,978.34 VAT plus shipping costs

or choose one of the following options:

Product inquiries Request education-price

Teledyne FLIR 78518-1301 | E86 thermal imaging camera Exx series, with 645,888 UltraMax temperature measuring points (464 x 348 px), Dual FOV 14° / 24° with two fields of view, MSX technology, refresh rate 30 Hz, -20°C to + 1,500°C, thermal sensitivity < 50 mK .

Display: 640 x 480px touchscreen
IR resolution: 464 x 348px
UltraMax: 645,888px
MSX: Yes
Built-in digital camera: 5 MP including built-in LED light
Temperature range: -20°C – 120°C || 0°C – 650°C || 300°C - 1,500°C
Accuracy: ±2°C / ±2%
Focus: Continuous Laser Distance Meter (LDM), One-Shot LDM, One-Shot Contrast, Manual
Digital Zoom: 1-4 continuously
Lens: Dual FOV 14° / 24° with two fields of view
Max. battery life: >2.5 h

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Article number:	78518-1301
Model:	E86 DUAL FOV
Resolution in pixels:	464 x 348
Temperature measuring points:	161472
Thermal sensitivity (mK):	50

Description

E86 | Thermal imaging camera 464x348px 14°/24° DUAL FOV, 30Hz, up to +1500°C, 50mK, MSX (78518-1301)

The Flir thermal imaging camera E86 of the EXX series helps to quickly uncover thermal problems in electrical and electronic systems, identify mechanical faults and carry out preventive maintenance measures.

The object is examined holistically, pixel by pixel (each pixel with its own temperature information) and provides the diagnostic results immediately. The fully equipped one-hand infrared camera with built-in digital camera combines an infrared and real image with the MSX picture-in-picture function : A daylight image is overlaid by the radiometric infrared image at the same time. In this way, critical problems can be identified even faster and more precisely.

The measurements/thermographic images are saved as JPG with fully radiometric measurement data per pixel.

The FLIR E86 supports FLIR Inspection Route and allows integration of FLIR Thermal Studio and FLIR Research Studio softwares . FLIR Inspection Routes guides the user along a predefined route of inspection points, allowing them to collect images and data in a structured way. FLIR Ignite enables E86 images to be automatically uploaded directly from the camera to the cloud for easy and secure storage and sharing.
