Chauvin Arnoux P01160541 | CA8333 network analyzer 4x V and 3x I inputs without current clamps

Manufacturer number: P01160541

Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Chauvin Arnoux P01160541
Ready to ship in 5 to 10 business days

CHF 3,879.00

plus VAT. CHF 4,193.20 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries
Highlights Documents / Downloads Description Scope Related Articles

Chauvin Arnoux 01160541 | Power and Energy Analyzer CA8333.

  • Number of measuring channels: 3x U / 3x I
  • Number of inputs: 4x V / 3x I
  • Voltages: TRMS AC + DC up to 1000 V.
  • Currents: TRMS AC + DC from 5 mA to 10 kA depending on the current sensor
  • frequency
  • Services: W, VA, var, VAD, PF, DPF, cos φ, tan φ
  • Energies: Wh, varh, VAh, VADh, BTU, TEP, toe, Joule
  • Harmonics of rank 0 to 50, phase
  • Transients: up to 50
  • Inrush over 4 periods
  • Recording of selected parameters over a period of a few days up to several 2 weeks (depending on the sampling interval)
  • 4000 alarms in 10 different types
  • Peak detection
  • Vector representation (vector diagram)
  • Currently available in 27 languages
  • IP53 / IK08
  • USB interface
  • IEC 61000-4-30 class B
  • Dimensions / weight: 240 x 180 x 55 mm / 1.9 kg
  • Large selection of current sensors for currents from 5 mA to 10 kA.

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Datasheet
pdf | 2.17 MB
Userguide
pdf | 5.97 MB

Description

P01160541 | CA8333 network analyzer 4x V and 3x I inputs without current clamps

All parameters at a glance: With the Qualistar + CA 8333, monitoring and maintenance services for industrial, commercial or administrative buildings can quickly get an overview of the most important features of network quality. The range of functions of this power and energy analyzer makes it the ideal device for preventive maintenance and troubleshooting, and it can also be used to easily create complete energy balances for a system.

For the dimensioning of electrical systems and for the detection of switching errors, the CA 8333 has a transient mode with which the starting current can be determined over 4 mains periods.
The device is very handy and compact and also offers many calculated values and processing functions. The CA 8333 has 3 measurement channels for voltages and 3 measurement channels for currents and it simultaneously records and saves all measured parameters, the transients, the alarms and the waveforms.

When connected, the device automatically detects the current sensors used. Different current sensors can even be used at the same time and the measurement data can always be read directly by setting the transformer ratios.

The Qualistar + convince with user-friendliness on site:

  • direct access to the main functions (configuration ....)
  • direct access to the measurements (harmonics, flicker ...)
  • Voltage and current inputs marked by colored rings
  • Large TFT color screen with optimal readability
  • 13 hours of battery operation

The numerous measuring and monitoring functions make the Qualistar + CA 8333 a very versatile device. It is suitable for voltages up to 1,000 V in CAT III and 600 V in CAT IV.

Software: The measurement results of the Qualistar series can be evaluated with two software: PAT is available as standard and DataView® as an option. With them, the user can configure the devices, transfer, process and analyze measurement data. In addition, DataView® offers the possibility of creating standards-compliant reports on the voltage quality.

Special accessories: With the ESSAILEC measuring cable, tests can be carried out on meters, on built-in protective relays or on secondary circuits of voltage or current transformers without interrupting the power supply.

All Qualistar + is supplied with a set of colored rings / pins, which can be used to color-code the measuring lines and inputs depending on the country requirements or personal taste.

Lieferumfang


  • An analyzer Qualistar + with 1 bag for accessories, 5 voltage measuring lines 3 m long with Ø 4 mm banana plugs, 5 alligator clips, 1 set with 12 colored identification parts for measuring lines and connection sockets, 1 screen scratch protection film (already attached), 1 USB cable, a power cord, a power supply, 1 safety data sheet, 1 CD with operating instructions in several languages and 1 CD with the evaluation software (Power Analyzer Transfer).

Accessoires (14 products )

Chauvin Arnoux P01102059
Chauvin Arnoux P01102059
Screen protection film for CA8335 / CA8334B / CA8332B
Delivery time upon request
CHF 45.00
Chauvin Arnoux P01120079B
Chauvin Arnoux P01120079B
PAC93 current probe, DC up to 1400A for CA833x, 1 piece
