Chauvin Arnoux P01160511 | CA8331 network analyzer 4x V and 3x I inputs without current clamps

Manufacturer number: P01160511

Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
Chauvin Arnoux P01160511
1 in stock. Ready to ship in 1 business day

CHF 2,365.00

plus VAT. CHF 2,556.56 VAT plus shipping costs

or choose one of the following options:
Product downloads Product inquiries
Highlights Documents / Downloads Description Scope Related Articles

Power and Energy Analyzer CA8331 from Chauvin Arnoux.

  • Number of measuring channels: 3x U / 3x I
  • Number of inputs: 4x V / 3x I
  • Voltages & currents: TRMS AC + DC, frequency
  • Services: W, VA, var, VAD, PF, DPF, cos φ, tan φ
  • Energies: Wh, varh, VAh, VADh, BTU, TEP, toe, Joule
  • Harmonics of rank 0 to 50, phase
  • Flicker (Pst and Plt)
  • Recording of selected parameters over 4 hours up to 2 weeks (depending on the sampling interval)
  • Peak detection
  • Vector representation (vector diagram)
  • IP53 / IK08
  • USB interface
  • Dimensions / weight: 240 x 180 x 55 mm / 1.9 kg

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Datasheet
pdf | 2.17 MB
Userguide
pdf | 5.97 MB

Description

P01160511 | CA8331 network analyzer 4x V and 3x I inputs without current clamps

All parameters at a glance: With the Qualistar + CA 8331, monitoring and maintenance services for industrial, commercial or administrative buildings can quickly get an overview of the most important features of network quality.

The device is very handy and compact and also offers many calculated values and processing functions. The CA 8331 power and energy analyzer has 3 measuring channels for voltages and 3 measuring channels for currents.

When connected, the device automatically detects the current sensors used. Different current sensors can even be used at the same time and the measurement data can always be read directly by setting the transformer ratios.

The Qualistar + convince with user-friendliness on site:

  • direct access to the main functions (configuration ....)
  • direct access to the measurements (harmonics, flicker ...)
  • Voltage and current inputs marked by colored rings
  • Large TFT color screen with optimal readability
  • 13 hours of battery operation

The numerous measuring and monitoring functions make the Qualistar + CA 8331 a very versatile device. It is suitable for voltages up to 1,000 V in CAT III and 600 V in CAT IV.
The measurement results of the Qualistar series can be evaluated with two software: PAT is available as standard and DataView® as an option.

Lieferumfang


  • An analyzer Qualistar + with 1 bag for accessories, 5 voltage measuring lines 3 m long with Ø 4 mm banana plugs, 5 alligator clips, 1 set with 12 colored identification parts for measuring lines and connection sockets, 1 screen scratch protection film (already attached), 1 USB cable, a power cord, a power supply, 1 safety data sheet, 1 CD with operating instructions in several languages and 1 CD with the evaluation software (Power Analyzer Transfer).

Accessoires (14 products )

Chauvin Arnoux P01102081
Chauvin Arnoux P01102081
BNC adapter for E3N connection to analyzer CA833X, CA82X0 and PEL103
Ready to ship in 5 to 10 business days
CHF 131.00
Chauvin Arnoux P01102095
Chauvin Arnoux P01102095
Dataview operating software for CA measuring and testing devices
Ready to ship in 5 to 10 business days
CHF 709.00
Chauvin Arnoux P01102131
Chauvin Arnoux P01102131
Adapter housing Essailec junction box for CA network analysis devices
Delivery time upon request
CHF 2,000.00
Chauvin Arnoux P01298055
Chauvin Arnoux P01298055
Transport bag No. 21 for hands-free operation CA833x
Delivery time upon request
CHF 119.00
Chauvin Arnoux P01120434B
Chauvin Arnoux P01120434B
MN93A current probe, AC up to 120A for mains analyzer
7 in stock. Ready to ship in 1 business day
CHF 325.00
Chauvin Arnoux P01120526B
Chauvin Arnoux P01120526B
A193 Current Clamp, AC, 450mm, for CA833x / 8352 1 piece
5 in stock. Ready to ship in 1 business day
CHF 287.00
Chauvin Arnoux P01120531B
Chauvin Arnoux P01120531B
A193 Current Clamp, AC, 800mm, for CA833x, 1 piece
Ready to ship in 5 to 10 business days
CHF 396.00
Chauvin Arnoux P01120323B
Chauvin Arnoux P01120323B
C193 current probe, AC up to 1200A for CA833x, 1 piece
Delivery time upon request
CHF 466.00
Chauvin Arnoux P01102059
Chauvin Arnoux P01102059
Screen protection film for CA8335 / CA8334B / CA8332B
Delivery time upon request
CHF 45.00
Chauvin Arnoux P01120079B
Chauvin Arnoux P01120079B
PAC93 current probe, DC up to 1400A for CA833x, 1 piece
