Teledyne FLIR Si2-LD | Industrial ultrasonic camera for leak detection, 2 kHz - 130 kHz, 0.3 m - 200 m (T912339)

Manufacturer number: T912339

Teledyne FLIR Si2-LD | Acoustic camera for industrial applications for detecting pressure leaks and mechanical faults, 2 kHz to 130 kHz, 0.3m to 200m (T912339).

  • Display: 5 inches with 1280 × 720 px, resistive touchscreen
  • Integrated LEDs with three operating modes

Acoustic measurement

  • Threshold detection: 20 kHz: -7 dB SPL || 35 kHz: 4 dB SPL || 50 kHz: 10 dB SPL || 80 kHz: 36 dB SPL || 100 kHz: 51 dB SPL
  • Bandwidth: 2-130 kHz
  • Directional resolution: 1° - 0.125°
  • < li>Operating distance: 0.3m - 200m
  • Leak detection and localization: Automatic leak detection, including estimated leak size and annual cost
  • Threshold for detecting the exit velocity in the event of leaks: 0.0032 l/min from 2.5 m, 0.0044 l/min from 6 m
  • Supported gases: compressed air, hydrogen, CO2, methane , Natural Gas, Helium, Argon, Ammonia
  • Other Acoustic Analysis Types: Mechanical Fault Detection

Imaging & Optics

  • Digital camera: color images with 12 MP
  • Camera field of view: 75° diagonal

  • Video refresh rate: Camera: 60 fps / Acoustic imaging: 30 fps / Screen: 70 fps
  • 8x digital zoom
  • Resolution video image : 1280 × 720 px

Analysis and Reporting

  • Online: FLIR Acoustic Camera Viewer (cloud service)
  • Offline FLIR Thermal Studio (desktop software)
  • Data transfer: Wi-Fi 2.4 GHz and 5 GHz IEEE 802.11.b/g/n/ac Wireless LAN USB memory stick
  • Internal memory: 128 GB (SD memory card)
  • External memory: USB 8GB, cloud storage capacity is unlimited

General

  • Rechargeable lithium Ion battery with a running time of up to 2.5 hours
  • Protection level: IP54
  • Security: IEC 62368-1
  • < li>Dimensions: 288 mm × 182 mm × 159 mm
  • Camera weight: approx. 1.2 kg
  • Total weight (camera and battery): approx .1.45kg

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Description

Si2-LD | Industrial ultrasonic camera for leak detection, 2 kHz - 130 kHz, 0.3 m - 200 m (T912339)

The FLIR Si2-LD is an industrial acoustic imaging camera specifically designed to detect pressure leaks and mechanical failures. It allows you to detect and reduce leaks in equipment, reducing your costs associated with compressed air and specialty gas leaks. In addition to these functions, it also identifies mechanical errors such as bearing problems, thus facilitating preventive maintenance to avoid downtime.

For pure partial discharge detection, choose the Si2-PD (T912305). If you need comprehensive coverage, including power, leak detection, and mechanical fault applications, choose the Si2-Pro (T912340).

The FLIR Si2-LD also offers comprehensive analysis tools, including the categorization of the discharge type in the device, the severity and the recommended actions. These features support rapid decision making and appropriate response planning.

In addition, the camera has fleet management functionality that ensures optimal use and maintenance of equipment in large industrial environments. It enables the integration of cloud data and OTA software updates, combining acoustic and thermal images in the same report.

Product features:

  • Detects, locates and measures compressed air and gas leaks, including bearing fault detection, from up to 200 m away
  • Integrated measurement and cost analysis for industrial gases such as ammonia, hydrogen, CO2, methane , Helium and Argon
  • One-handed operation with automatic tuning, 8x zoom and a 12 MP digital camera
  • Mechanical failure mode, automatic selection and optimization of filters makes it easier to find critical mechanical problems such as bearing errors
  • Fleet management functions for efficient tool use and maintenance in large operations

Main Applications:

  • Detection and quantification of leaks in manufacturing, production and assembly applications in all applications using compressed air
  • < li>Early leak detection to improve safety and compliance while minimizing costly repairs
  • Fast, accurate leak detection, increased efficiency and customer satisfaction in compressed air and gas equipment maintenance
  • Mechanical fault mode to detect faulty bearings, plan repairs and avoid downtime

Lieferumfang

  • Camera
  • Battery (2 pieces)
  • Battery charger

  • Power cord (4 pieces)
  • Carry strap
  • Hard case
  • License card: FLIR- Si Series Plugin for FLIR Thermal Studio, perpetual license
  • Printed documentation
  • USB memory stick
