Teledyne FLIR Si2-PD | Industrial Ultrasonic Camera for Partial Discharge Detection, 2 kHz - 130 kHz, 0.3 m - 200 m (T912305)

Name: Si2-PD | Industrial Ultrasonic Camera for Partial Discharge Detection, 2 kHz - 130 kHz, 0.3 m - 200 m (T912305)
Brand: Teledyne FLIR
SKU: T912305
Price: 17499.0 EUR
Availability: InStock

Manufacturer number: T912305

3 in stock. Ready to ship in 1 business day

€17,499.00

or choose one of the following options:

Request a quote Product inquiries Request education-price

Teledyne FLIR Si2-PD | Acoustic camera for industrial applications for partial discharge detection, 2 kHz to 130 kHz, 0.3m to 200m (T912305).

Display: 5 inches with 1280 × 720 px, resistive touchscreen
Integrated LEDs with three operating modes

Acoustic measurement

Threshold detection: 20 kHz: -7 dB SPL || 35 kHz: 4 dB SPL || 50 kHz: 10 dB SPL || 80 kHz: 36 dB SPL || 100 kHz: 51 dB SPL
Bandwidth: 2-130 kHz
Directional resolution: 1° - 0.125°
Severity assessment: Automatic assessment of severity using AI, including recommendations for appropriate actions in the camera

Imaging & Optics

Digital camera: color images with 12 MP
Camera field of view: 75° diagonal

Video refresh rate: Camera: 60 fps / Acoustic imaging: 30 fps / Screen: 70 fps
8x digital zoom
Resolution video image : 1280 × 720 px

Analysis and Reporting

Online: FLIR Acoustic Camera Viewer (cloud service)
Offline FLIR Thermal Studio (desktop software)
Data transfer: Wi-Fi 2.4 GHz and 5 GHz IEEE 802.11.b/g/n/ac Wireless LAN USB memory stick
Internal memory: 128 GB (SD memory card)
External memory: USB 8GB, cloud storage capacity is unlimited

General

Rechargeable lithium Ion battery with a running time of up to 2.5 hours
Protection level: IP54
Security: IEC 62368-1
Camera weight: approx. 1.2 kg
Total weight (camera and battery): approx .1.45kg

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Description

Si2-PD | Industrial Ultrasonic Camera for Partial Discharge Detection, 2 kHz - 130 kHz, 0.3 m - 200 m (T912305)

The FLIR Si2-PD is an industrial acoustic imaging camera specifically designed to detect partial discharge (PD). It provides an effective solution to detect and respond to PD, helping to reduce maintenance costs for electrical equipment.

The camera detects, locates, classifies and evaluates PD faults from a distance of up to 200 m and identifies PD problems that are 30 times smaller than previously possible. It provides both camera and software-based severity ratings, providing you with the decision support needed to make accurate maintenance decisions.

For specific applications, you can use the Si2-LD (T912339) for leak detection and Bearing Fault Detection or the Si2-Pro (T912340) for comprehensive power supply, leak detection and bearing fault detection applications.

The FLIR Si2-PD also provides comprehensive analysis tools, including categorizing the discharge type in the device , severity and recommended actions. These features support rapid decision making and appropriate response planning.

In addition, the camera has fleet management functionality that ensures optimal use and maintenance of equipment in large industrial environments. It enables the integration of cloud data and OTA software updates, combining acoustic and thermal images in the same report.

Product features:

Detect, locate, classify and assess partial discharge faults from a distance of up to 200 m
Detect partial discharges that are 30 times smaller than ever before
Assessing the severity of partial discharge problems and classifying the type of partial discharge in the camera and with the help of software provide first-class support in your decision-making
One-handed operation with automatic tuning, 8 -x zoom, a 12MP digital camera with IP54 protection
Designed to scale businesses with fleet management capabilities so managers can ensure the tool is used and maintained properly

Main Applications:

Monitoring of line and distribution conductors and associated components from long distances and therefore less need for emergency repairs
Inspection of transformers in substations to detect partial discharge problems early before they lead to a dangerous explosion, which also causes high costs

Find partial discharge problems in any high-voltage installation so that there are fewer complaints from the public about radio interference and audible noises

Lieferumfang

Camera
Battery (2 pieces)
Battery charger

Power cord (4 pieces)
Carry strap
Hard case
License card: FLIR- Si Series Plugin for FLIR Thermal Studio, perpetual license
Printed documentation
USB memory stick
