Teledyne FLIR T1020 | HD thermal imaging camera, 1,024 x 768 px, 28 ° optics (725010102)

Manufacturer number: 725010102

T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
T1020
Delivery time upon request

€37,849.00

or choose one of the following options:
Request a quote Product is already in cart Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Scope Related Articles

Flir T1020 / thermal imaging camera with 786,432 temperature measuring points (1,024 x 768 pixels), with 28 ° interchangeable lens, a measuring range from -40 ° C to + 2,000 ° C, a thermal sensitivity <0.02 ° C. With Multi Spectral Dynamic Imaging (MSX) and the image optimization technology UltraMax to quadruple the number of pixels to up to 3.1 megapixels for even more precision and depth of field.

  • The most ergonomic camera with the highest real resolution (1,024 x 768 pixels)
  • Temperature measuring points 786.432
  • Accuracy ± 2 ° C / ± 2% (partly ± 1 ° C / ± 1%)
  • Thermal sensitivity <0.02 ° C (<20 mK NETD)
  • MSX: Provides visible details over the thermal image with full resolution - markings and positions can be recognized precisely
  • UltraMax: Unique image optimization technology for a 4 times higher image resolution (allows the measurement of smaller objects, increases the resolution and reduces noise
  • Measuring instruments: 10 spot meters, 5 + 5 areas (fields and circles) with max./min./ average
  • Emissivity correction: Variable from 0.01 to 1.0 or by selection from the material list
  • Measurement correction: emissivity, reflected temperature, relative humidity, air temperature, object distance, external IR window compensation
  • Color palettes: iron, rainbow, rainbow HC, white hot, black hot, arctic, lava
  • Configurable image overlay functions
  • Traditional level / span
  • Reset the frame counter
  • 4 different programmable buttons ensure an effective way of working
  • Image display / display 8.9 cm (3.5 inch) color LCD monitor with touchscreen
  • Optional interchangeable lenses 50 μm, 12 ° and 45 °
  • Ultrasonic focus drive enables faster autofocusing, as well as improved manual focusing
  • Built-in digital camera with 5 megapixels
  • GPS, compass
  • Wi-Fi, Bluetooth, HDMI
  • Laser, eyepiece
  • 2.5 hours of battery life
  • Storage on the SD card in the camera lossless compression (CSQ format) 1,024 x 768 with 30 Hz
  • USB data streaming to the PC at 30 Hz via Tools + and ResearchIR
  • Magnesium housing, protection class IP54, 25 g shock, 2 g vibration
  • Integrated tripod adapter
  • Dimensions: approx. W143 x H195 x D95 mm
  • Weight: approx.1.9 kg
  • Warranty 2 years on the camera and 10 years on the detector

Technical Data

Documents & Downloads

Datasheet
pdf | 0.39 MB
Userguide
pdf | 4.17 MB

Description

T1020 | HD thermal imaging camera, 1,024 x 768 px, 28 ° optics (725010102)

Megapixel thermal imaging camera with the highest geometric resolution of 1,024 x 768 pixels for professional thermographers and scientists.

This real resolution reveals even more details and opens up new applications in the areas of research, development, production, quality assurance, energy supply and also in building technology. The rubberized surface and the new lens technology bring outstanding ergonomic advantages for the user.

Lieferumfang

  • Thermal imaging camera (infrared camera) with lens, batteries (2 pcs.), Battery charger, HDMI-to-HDMI cable, hard case, Bluetooth headset, SD memory card, large eyecup, lens cover, shoulder strap, power supply (including multiple plugs), USB cable (Standard-A to Mini-B), calibration certificate, FLIR Tools + license card, documentation on CD-ROM and in printed form.
