Teledyne FLIR A8581 | SLS thermal imaging camera (7.5 - 12µm), 1280x1024px, f/2.5, 44Hz GigE / 60Hz CXP

Manufacturer number: 29444-201

Delivery time upon request

On Request

or choose one of the following options:
Product inquiries Request education-price
Highlights Description

Teledyne FLIR A8581 | SLS thermal imaging camera (7.5 - 12µm), 1280x1024px, f/2.5, 44Hz GigE / 60Hz CXP.

  • Auflösung: 1280 x 1024
  • Detektorraster: 12 µm
  • Spektralbereich: 7,5 µm (unterer), 11,5–12,5 µm (oberer)
  • Detektortyp: Strained Layer Superlattice (SLS)
  • Blendenzahl Kamera: f/2.5
  • Dynamikbereich: 14 Bit
  • Thermische Auflösung (NETD): ≤45 mK (≤40 mK typisch)
  • Bildrate [Vollbild]: Programmierbar, 0,0015 Hz bis ~45 Hz (GigE), 60 Hz (CXP)
  • Standard-Temperaturmessbereich: -20 °C bis 650 °C
  • Fokus: Motorgetrieben (kompatibel mit manuellen Objektiven)
  • Anzeige: Schnappschuss (Einzelbild)
  • Betriebsfähigkeit: ≥98 % (≥99 % typisch)
  • Mindest-Integrationszeit: 480 ns bis zum Vollbild
  • Objektivanschluss: FLIR FPO-M (Bajonettverschluss mit vier Haltelaschen, motorgetrieben)
  • Pixeltakt: 100 MHz
  • Zoom: Automatisch, variabel
  • Genauigkeit: ±2 °C (±1 °C typisch) unter 100 °C, ±2 % des Ablesewerts (±1 % typisch) über 100 °C
  • Abmessungen [L × B × H] ohne Objektiv: 226 x 117 x 135 mm
  • Gewicht [ohne Objektiv]: 3,4 kg

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Description

A8581 | SLS thermal imaging camera (7.5 - 12µm), 1280x1024px, f/2.5, 44Hz GigE / 60Hz CXP

An LWIR camera (long-wave infrared camera) is a special type of infrared camera that operates in the long-wave infrared range of the electromagnetic spectrum. This range covers wavelengths from around 7.5 to 12 micrometers (µm).

Here are some features and applications of the Teledyne FLIR A8581 SLS thermal imaging camera:

  • Specific wavelength sensitivity: This camera is optimized for the long-wave infrared range (7.5-12 µm) and enables precise detection and imaging of temperature differences and thermal radiations that are not visible in visible light.

  • High resolution and image quality: With a resolution of 1280 x 1024 pixels, the camera offers excellent detail and image quality. This makes it ideal for applications that require particularly detailed and clear thermal images.

  • Fast frame rate: The camera supports frame rates of 44 Hz with GigE and 60 Hz with CXP (CoaXPress), which enables fast and precise capture of thermal events. This frame rate flexibility is particularly useful for applications that require different transmission rates.

  • High sensitivity: With a high thermal sensitivity, the camera provides precise measurements and detection of subtle temperature differences, making it ideal for demanding measurement and monitoring tasks.

  • Rugged design: The camera is designed for use in demanding conditions and can withstand extreme temperatures and mechanical stress. This ensures reliable performance even in harsh environments.

  • Flexible data transmission: Support for both GigE and CXP enables flexible and fast data transmission, which facilitates integration into various systems and enables comprehensive image analysis.

In summary, the Teledyne FLIR A8581 SLS thermal imaging camera is a powerful LWIR camera that is suitable for a wide range of applications in research, development and industrial monitoring due to its high resolution, fast frame rate and robust design.

About the Manufacturer

Teledyne FLIR
Teledyne FLIR
Teledyne FLIR is the world's largest manufacturer of thermal imaging cameras and thermographic instruments. Teledyne FLIR covers an incredibly wide range and has the optimal thermal imaging camera for every application, whether construction, research and development or industrial manufacturing. Since 2010 dataTec is Platinum Distributor of FLIR and, of course, now of Teledyne FLIR.
