NI 783130-01 | PXIe-4081, performance-optimized digital multimeter with 7 1/2 digits and digitizer up to 1000 V.

Name: 783130-01 | PXIe-4081, performance-optimized digital multimeter with 7 1/2 digits and digitizer up to 1000 V.
Brand: NI
SKU: 783130-01
Price: 6620.0 EUR
Availability: OutOfStock

Manufacturer number: 783130-01

Delivery time upon request

€6,620.00

or choose one of the following options:

Product inquiries

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Basic accuracy with DC voltage (ppm):	12
Bustype:	PXI Express
Connection type front:	1-Pin, Weiblich Bananenstecker
DC voltage range:	-1000 V bis 1000 V
LC meter:	Nein
Measurements per second/sampling rate (MS/s):	1.8
Module width:	1
Number of positions:	7.5
Protectively coated:	Nein
Samplerate:	1.8 MS/s
With case:	Ja
max. Measuring range DC (V):	1000
min. Measuring range DC (mV):	-1000000

Detaildescription

783130-01 | PXIe-4081, performance-optimized digital multimeter with 7 1/2 digits and digitizer up to 1000 V.

The PXIe ‑ 4081 is a high-performance digital multimeter (DMM) with 7½ digits that offers the measurement functionality of two common measuring devices: a high-resolution DMM up to 1000 V and a digitizer. As a DMM, the PXIe ‑ 4081 enables fast and accurate DC / AC voltage, DC / AC current, two- / four-wire and frequency / period measurements as well as diode tests. As an isolated digitizer for high voltages, the PXIe ‑ 4081 is used to acquire waveforms with sampling rates of up to 1.8 MS / s.

Product features:

Bus type: PXIe
Resolution: 75
DC voltage range: -1000 V to 1000 V
DC current range: -3 A to 3 A.
LC measuring device: No.
Maximum sampling rate: 1.8 MS / s
Basic accuracy with DC voltage: 12 ppm
