NI 782953-01 | PXIe-7971R FlexRIO FPGA Module (Kintex-7 K325T)

Manufacturer number: 782953-01

NI 782953-01
NI 782953-01
NI 782953-01
Delivery time upon request

€11,600.00

or choose one of the following options:
Product downloads Product inquiries
Highlights Technical Data Documents / Downloads Description Related Articles

NI 782953-01 | PXIe-7971R FlexRIO FPGA module (Kintex-7 K325T).

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Catalog
pdf | 5.12 MB
Overview
pdf | 1.35 MB
Datasheet
pdf | 0.52 MB
Configuration guide
pdf | 1.88 MB

Description

782953-01 | PXIe-7971R FlexRIO FPGA Module (Kintex-7 K325T)

The PXIe ‑ 7971 provides flexible, customizable I / O for LabVIEW FPGA. The module has 132 single ‑ ended I / O lines that can be configured as 66 differential line pairs. The PXIe ‑ 7971 can be combined with FlexRIO adapter modules that have analog and digital high ‑ performance I / O. Both modules together result in a configurable measuring device that can be programmed with the LabVIEW FPGA software. The PXIe ‑ 7971 supports peer ‑ to ‑ peer data streaming, which allows data to be transferred between multiple FPGA or certain PXI ‑ Express modules without having to send the data to the host processor. This allows you to add FPGA capabilities to powerful NI digitizers with NIST-compliant calibration, or to transfer FPGA algorithms to multiple FPGAs in processing-intensive applications.

Product features:

  • FPGA: Kintex-7 325T
  • FPGA slices: 50950
  • Block RAM (BRAM): 16020 kbit
  • DSP slices: 840
  • Dynamic RAM (DRAM): 0 MB
  • PXI backplane connection: PCI-Express Gen2 x 4
