NI 780979-01 | NI 9208E, power input module for industrial systems, with DSUB, 16 channels, board only

Name: 780979-01 | NI 9208E, power input module for industrial systems, with DSUB, 16 channels, board only
Brand: NI
SKU: 780979-01
Price: 1060.0 EUR
Availability: OutOfStock

Manufacturer number: 780979-01

Delivery time upon request

€1,060.00

or choose one of the following options:

Product inquiries

780979-01 | NI 9208E, power input module for industrial systems, with DSUB, 16 channels, board only.

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Analogue input isolation:	Ch-Earth Ground Isolation, 60 VDC Isolierung Kanal gegen Masse
Bustype:	C Series
Connection type front:	37-Pin, Männlich D-Sub
Current measurement:	-20 mA bis 20 mA
Max. Number of differential analogue input channels:	0
Max. Number of ground-related analogue input channels:	16
Measured electrical signal:	Current
Measurements per second/sampling rate (MS/s):	0.0005
Module width:	1
Protectively coated:	No
Resolution of the analogue input:	24 bit
Samplerate:	500 S/s
Simultaneous scanning:	No
With case:	No

Description

780979-01 | NI 9208E, power input module for industrial systems, with DSUB, 16 channels, board only

The sbRIO-9208 module is designed for industrial systems. The integrated high-resolution mode with a noise reduction of 50/60 Hz removes low-frequency noise. The module offers a high channel density in order to reduce the number of necessary system modules, so that slots remain free for other types of measurement and the total costs of the system per channel are lower. The sbRIO-9208 module has a standard D-Sub connection for cables and connection blocks. Modules without a housing are designed for OEM applications.

Accessoires (5 products )

NI 960460-03

ANSI Compliant Calibration Certificate for sbRIO-9208 (780979-01-ANSI)

Delivery time upon request

€425.00

NI 960460-01

Traceable Calibration Certificate for sbRIO-9208 (780979-01-CAL)

Delivery time upon request

€275.00

NI 960680-100

Standard Service Program (SSP) for sbRIO-9208, 3 years (780979-01-S3)

Delivery time upon request

On Request

NI 960460-04

ISO 17025 Calibration Certificate for sbRIO-9208 (780979-01-ISO)

Delivery time upon request

€545.00

NI 960680-101

Standard Service Program (SSP) for sbRIO-9208 with Traceable Calibration, 3 years (780979-01-SC3)

Delivery time upon request

€469.10
